H03846‐00.A1.EN–2012/10 15
4.2.2Troubleshooting
allsolderingworkmustbecarriedoutbyasomeonequalifiedtodoso.
replacementpipesmustalwaysbemadeofcopperincompliancewithstandardNFEN12735‐1.
leakdetection;pressuretest:
- neveruseoxygenordryair,riskoffireorexplosion,
- usedrynitrogenorthemixtureofnitrogenandrefrigerantindicatedontheinformationplate,
- thetestpressureforboththehighand lowpressurecircuitsmustnotexceed20barand15barinthecase
thedeviceisequippedofthemanometeroption.
the high pressure circuit pipes are ma
de of copper and have a diameter equal to or greater than 1’’5/8. A
certificateasindicatedin§2.1incompliancewithstandardNFEN10204willberequestedfromthesupplierand
filedininstallationtechnicaldocumentation.
technicaldatarelativetothesafetyrequirementsofthevariousapplicabledir
ectivesmustbeindicatedonthe
informationplate.
Thisdatamustberecordedintheinstallationinstructionsforthedevicewhichareincludedintheinstallation
technical file: model, code, serial number, maximum and minimum OT, OP, year of manufacture, EC label,
manufacturer’s address, refrigerant and weight, electrical parameters, therm
o‐dynamic and acoustic
performances.
4.3Spareparts
Spareparts Itemnumber Representation
HygroControlsensor WCE03431
Filter
CAEambiance 375x445x20mm(x2) WSD01908*
CAElateral 555x455x23mm WSD01909
CAErear 788x400x23mm WSD01910
Omega10‐14‐16‐20 615x525x25mm(x2) WSD01916*
Omega28 547x400x22mm(x6) WSD03350*
Fanbelt
CAE
Omega10‐14‐16
WGA02968
Omega20 WGA02969
Omega28(x2) WTR02357*
*Referenceforonepart
4.4Recyclingtheproduct
This symbol means that the equipment must not throw it into your household waste. It will be
collected selectively so that it can be reused, recycled or recovered. Any substances it may contain
whicharepotentiallydangeroustotheenvironmentwillbeeliminatedorneutralised.
Enquirewithyourretailerforthecondi
tionsthatapplytotherecyclingofyourproduct.
