H03846‐00.A1.EN–2012/10 16
5.Troubleshooting
5.1StatusandfaultsintheECP600settings
Terminals Description
N‐L mains‐supply230Vac‐50HztotheECP600regulator
20‐21 outputfromcompressorsupply230Vac‐50Hz
30‐31 230Vac‐50Hzoutput(usedwiththewatercondenseroption)andprotectedbytheECP600fuse
22‐23 ventilator230Vac‐50Hzoutput
25‐24 outputforcirculatorhotwaterbatteryoption230Vac‐50Hz
26‐27 outputalarmreport230Vac‐50Hz
28‐29 outputcontact“NO”(withoutpolarity)controlofheatsourcehotwaterbatteryoption
11–12‐13 InputcontrolsensortypePTC(inletordefrost)
4‐5 powersupply12Vac‐50Hz
7 input6Vac‐50Hzgivenbythehygrostatfunction(requestactiveif6Vac‐50Hzbetween7and4)
2 input6Vac‐50Hzgivenbythether mostatfunction(requestactiveif6Vac‐50Hzbetween2and4)
8
input12Vac‐50Hzfanheatfault(shuntednotactive)(faultactiveif0Vac‐50Hzbetween8and4,
LEDsA1andA2areON)
9
input12Vac‐50HzfaultsBPand/orHP,and/orphaseorder(three‐phaseappliance)(faultactiveif
0Vac‐50Hzbetween9and4,LEDsA1andA3areON)
10
input12Vac‐50Hzcompressor heatfault(shuntednot active)(faultactive if0Vac‐50Hzbetween
10and4,LEDsA1andB1areON)
Hygro‐
Thermostat
LCD
A‐B‐Sh‐4‐5
Notused
switchVI/VP
“intermittentventilation”(standardsetting)
or“permanentventilation”(topermanentlycirculatethepoolhallair)
Theventilationisactivewhen:
- dehumidificationistrigger ed,
- adefrostingcycleisstarted,
- poolhallairheatingistriggered,
- activeforatleast5minutesinonehourwithoutanyofthesetriggers.
OnVP,thecompressorstartsafteradelayof1minute.
Leds Description
A2
fanheatfault
TriggeringofauxiliarycontactQ1.1forthermalrelayQ1
A3
highorlow
pressure
switchfault
triggeringHPand/orLPswitchand/orphaseorderrelayKA4(onlyonthree‐phased appliance)
- HP: check that the ventilator is operational, that the air filter iscleanandthe belt is tight
enough,
- LP:insufficientgas,callaspecialist,
- KA4:checkforthepresenceofthe3phases,ifso,see§3.2.
B1
compressor
heatfault
TriggeringofauxiliarycontactQ2.1forthermalrelayQ2
