OPERATION
ZIPPER MASCHINEN GmbH www.Zipper-Maschinen.at 28
ZI-BSF1500
NOTE: The “Closed” position of the choke lever (6) enriches
the fuel mixture for starting a cold engine.
The “Open” position (5) provides the correct fuel mixture for
normal operation after starting and for restarting a warm
engine.
4. Move the choke lever (4) to the “Closed” position (6), only for
a cold engine.
5. Set the throttle lever (7) to the idle position between the
“slow” position(8).
6. Grasp the safety bar (10) and the handle (11) with your left
hand.
7. Grasp the starter handle (12) and pull it out slowly. The
resistance is strongest at a certain point. This point
corresponds to the compression point. Let the rope roll back
a little from this point and then pull it out forcefully.
NOTE: Do not pull the starter rope all the way to the end and
do not let it rewind after pulling, but only rewind it quickly.
8. Move the choke lever to “Open” (5) when the engine is
running.
15.4.3 Grind tree stump
Rotating grinding tool!
Risk of injury due to sharp cutting wheel. Contact with rotating parts of the grinding
tool can lead to serious injuries!
Keep hands and feet away from the grinding tool!
• Bring the machine to the start of the tree stump (to do this,
release the brake and bring it closer).
• Then activate the brake again (1).
• The milling tool can be moved sideways by releasing the
handle (2) (this allows the milling head to swivel to the left
and right, the machine (wheels) remain in the selected
parking position.
• Press the handle (3) down to lift the milling tool off the
ground.
• Start the machine
• Turn the throttle lever (6) downwards to engage the
centrifugal clutch (to the fast-position). The milling tool
starts to rotate.
• Swivel the cutter to the side of the tree stump and guide it
straight into the tree stump with light pressure. As soon as
you penetrate the tree stump, swivel to the side until you
reach the edge of the tree stump. Change direction and
swing back in the other direction until you feel the cutter
reach the other edge of the tree stump.
• Pay attention to the engine noise and accelerate
sufficiently.
• If the belt or clutch squeaks, you are overloading the
machine. Reduce the load (lower feed rate / slower lateral
swing or reduce the penetration depth.
• If you cannot move the machine sideways, lift it slightly.
• You can cut solid roots with the machine by driving directly
through them.
• When shredding larger stumps, shavings can collect under
the tires to remove them, proceed as follows:
- Release the brake (2) and pull the machine towards you
so that the pile of chips is directly under the cutting
wheel.
- Place the cutting wheel on the chip pile. The material is
discharged from the machine area.
12
WARNING
