23
Print Operations
This section provides media and print handling, font and language support, and the setup
of less common printer configurations.
Long Term Printer In-activity or Storage
Overtime the printhead may stick to the platen (drive) roller. To prevent this, always store
the printer with a piece of media (a label or paper) between the printhead and platen roller.
Do not ship the printer with a roll of media installed or damage to the printer or media may
result.
Supported Print Media
This printer is designed to print on label rolls or fan-fold media ranging in size from
50.8 mm to 102 mm (2 inches to 4 inches) wide. The labels must be on liner backing
(web) and have a at least 3 mm gap between the labels for optimal operation. The printers
label gap default is set a little more than the 3 mm and adjusts to any differences in gap
distance from roll to roll and label to label.
• The media width (including web) is 86mm - 107mm (2.0” - 4.21”) including the roll
core and media backing (or web).
• Direct Thermal Media only
• Maximum media length shall be 9” (228.6mm)
• Minimum media length shall be Tear - 1” (25.4mm)
• Inner core diameters shall be 1" (25.4mm) to 1.57" (40mm)
• Maximum media roll outside diameter shall be 5.00" (127mm)
• Media Thickness shall be 0.0055” (0.014 mm) - 0.007" (0.018 mm)
• Media Sensing: Gap, no support for black mark or black line detection
• Media Types: Roll-fed or fan-fold, die cut direct thermal labels. There is no support
for tags, continuous media (receipt) or labels without gaps between labels.
• The printer typically uses roll media, but you can also use fan-fold.
Important • Zebra strongly recommends the use of Zebra-brand supplies for continuous
high-quality printing. A wide range of label materials have been specifically engineered to
enhance the printing capabilities of the printer and to prevent premature printhead wear.
To purchase supplies, go to http://www.zebra.com/supplies
