4 - 6 8585/8595 Vehicle-Mount Computer User Guide
7. Click OK again for the changes to take effect.
Tips and Tricks
Note that according to the EIA-232-E specification, the maximum cable length is 15 m at 19,200 bps.
By using a correctly terminated twisted-pair cable, however, up to 1,200 m at 100 kbps can be achieved
according to the EIA-422-A specification. With a data rate of 1 Mbps and a high-quality cable, it is possible to
reach cable lengths of up to approximately 400 m.
Malfunctions in the RS-232 connections are frequently caused by ground loops. If both end devices establish a
ground connection via RS-232 but do not share the same ground potential in their power supply circuits, then
compensation currents may result. This is particularly noticeable with long cables.
These compensation currents, which are also present at the ground point of the RS-232 connection, may
significantly degrade signal quality and effectively stop the data flow. In challenging environments, electri-
cally-isolated connections (via external converters) or differential systems (RS-422/485 port) are strongly
recommended.
Internal Devices
Chipset
The 8585 computer is equipped with a chipset which controls the communication between all
function modules.
The chipset converts the signals it receives from the CPU into memory access, flash access and other similar
actions. Likewise, it transmits requests from peripheral devices to the CPU. Input devices such as the mouse
or keyboard also communicate with the system via this chipset.
VGA Adaptor
The 8585 is equipped with a VGA-compatible adaptor. This adaptor controls the integrated display.
Onboard Sound Controller
The 8585 is equipped with an onboard sound controller.
This controls the audio output via the internal speaker, or the optional Speaker/Mic with push-to-talk function
(Model Number M1000).
Network Adaptor (10/100/1000)
The 8585 is equipped with a 10/100 Mbit network adaptor. This adaptor features an RJ45 port.
The network controller undertakes the entire task of connecting the hardware to the network.
The RJ45 connection port features two integrated status LEDs. They display the following messages:
Caution:
Property
Damage
Please note that you have to configure the scanner correctly to RS-232 and the above set BAUD rate
following the scanner manufacturer's guidelines. Otherwise the software wedge will not function
properly.
