Operation 4 - 5
Pre-installed on Flash
When an 8585 with a pre-installed operating system is started, the operating system is loaded following the
BIOS boot messages.
System-specific device drivers — such as those for graphic, sound, network and touchscreens — are also
pre-installed.
In 8585 units with a pre-installed operating system, the system is located on the C partition.
Installing on Flash
When an 8585 is started up for the first time without a pre-installed operating system, the user needs to carry
out a number of steps that will vary depending on the system to be installed. Refer to the relevant operating
system manual for specific instructions.
Special Features of the Operating Systems
If the 8585 is running MS Windows XP Embedded or Windows Embedded Standard 7, not all USB devices will
be supported.
Serial Port
The 8585 is equipped with an externally accessible serial interface COM1.
Resources for the serial port are pre-defined in the system architecture and automatically managed by
the BIOS.
COM1 as a Power Supply
The COM1 port can optionally supply externally connected equipment with +5 V of power.
The voltages are protected by internal fuses which limit the total consumed current to 1.1 A at 5 V.
Depending on the specific system configuration, the maximum current consumption may be significantly lower.
Serial Port Printers
Printers with a serial port can be connected to the 8585.
Serial Port Bar Code Scanners
To activate the integrated scanner software wedge under MS Windows 7
1. Open the Start menu and navigate to Settings>Control Panel>Accessibility.
2. Select the General tab.
3. Select Support accessibility options.
4. Click Settings.
5. Configure the desired COM1 port and BAUD rate.
6. Confirm the change with OK.
Caution:
Property
Damage
The installation and configuration of the operating system should only be carried out by professionals
familiar with the system environment.
