Apply plenty of grease (included with the new pump tubing) to the longer section of new calibrator pump tubing.
Insert the new pump tubing around the pump roller assembly and into calibrator pump C2A. Make sure the short section
of tubing is on the left side of the pump. The tubing attached this fitting connects to the left fitting on waste module 2.
Place a red pump head cover onto the cal pump and press until it snaps into place.
Connect the tubing from the right side of the pump to the second fitting from the top of the top manifold.
Connect Cal bottle tubing marked C2A to the matching fitting on the opposite side of the manifold.
Figure 9-12
C2B
Apply plenty of grease (included with the new pump tubing) to the shorter section of new calibrator pump tubing.
Insert the new pump tubing around the pump roller assembly and into calibrator pump C2B. Make sure the short section
of tubing is on the left side of the pump. The tubing attached this fitting connects to the right fitting on waste module 2.
Place a red pump head cover onto the cal pump and press until it snaps into place.
Connect the tubing from the right side of the pump to the bottom fitting of the top manifold.
C2A
B2
B3
C2B
C3A
C3B
B2
C2A
C2B
B3
C3A
C3B
C1A
B1
C1B
