18
9. Attach double sided adhesive to the door panel in the lower
half, to temporarily aid in door alignment. These pieces of
adhesive can be removed later after getting all the holes
perfectly aligned.
Double sided adhesive
10. Insert one of the wood blocks from the packaging across the
door opening to prop the door slightly open.
11. Align the two door studs to the referenced tracks on the door,
lifting up the door until the top panel is flush with the top of the
dishwasher door.
12. While holding the alignment, press on the lower section of the
door, to allow the double sided tape to grab and hold your
alignment.
13. If this process needs adjusting, Use a plastic putty knife
between the panel and the door to relieve the double sided
tape and free the panel.
14. Open the door and panel together to the fully open position,
making sure the panel has not shifted.
15. Consider the material choice of the custom panel and attach
the 1st of the 4 included door panel screws using a Phillips
screwdriver. Check to ensure the door panel is still aligned.
Repeat the screw installation for the 2
nd
hole.
B
A
C
A. 4 x 38 mm Phillips head screw (4)
B. #2 Phillips screwdriver
C. Custom panel
16. Check to ensure the door panel is still aligned.
17. Repeat the screw installation for the last 2 screws.
18. If desired, remove the screws and the panel to remove the
temporary double sided tape.
19. If the door to cabinet gaps are not even, make an adjustment
to the dishwasher by loosening all 4 screws mounted to the
adjacent cabinets. Make the position adjustment.
20. Retighten all 4 screws mounted to the adjacent cabinets. All
screws need to be tight to prevent the dishwasher from
moving.
Electrical Connection
If house wiring does not reach into the adjacent cabinet to the
dishwasher junction box mounting location, the house wiring will
first need to be corrected by a qualified electrician in conformance
with the National Electrical Code, ANSI/NFPA 70 - latest edition,
and all local codes and ordinances.
WARNING
Fire Hazard
Use only the junction box supplied with the product
when making electrical connections.
Do not bypass the junction box.
Failure to follow these instructions can result in death,
fire, or electrical shock.
