14
Prepare Dishwasher
WARNING
Tip Over Hazard
Do not use dishwasher until completely installed.
Do not push down on open door.
Doing so can result in serious injury or cuts.
WARNING
Excessive Weight Hazard
Use two or more people to move and install or uninstall
appliance.
Failure to do so can result in back or other injury.
Remove Access and Toe Panels
8. Access panel
Using a 1/4" (6.35 mm) nut driver or Phillips screwdriver,
remove 4 screws attaching Access panel to dishwasher.
Slowly lift and remove the Access panel from the hooks of
dishwasher.
9. Toe panel
After removing the access panel remove the toe panel.
10. Measure cabinet opening
There is a leveling system on the front of the base carrier.
Once the dishwasher is within the cabinet space, use the
leveling adjuster to adjust the dishwasher up to the height of
the cabinet.
Adjust both front and back leveling legs to the same height.
Connect Water Line to Fill Valve
The dishwasher may come with the inlet hose already attached
with a threaded connection. It needs to be connected to the inlet
end on the house connection.
11. Leak Detection System Hose (on some
models)
Use the Leak Detection System hose with included 3/8"
(9.5 mm) to 3/4" (19 mm) water inlet adapter.
