22
MAINTENANCE INSTRUCTIONSMAINTENANCE INSTRUCTIONS
Contact your authorized Commercial Laundry distributor. To
locate your authorized Commercial Laundry distributor, or for
web inquiries, visit www.whirlpoolcommerciallaundry.com.
If you cannot locate your distributor, the Commercial Laundry
Support Center will answer any questions about operating
or maintaining your dryer not covered in the Installation
Instructions.
Just dial 1-800 NO BELTS (1-866-698-2538) — the call is toll
free.
When you call, you will need the dryer model number and serial
number. Both numbers can be found on the serial-rating plate
located in the dryer door opening.
IF YOU NEED ASSISTANCEIF YOU NEED ASSISTANCE
■ Clean lint screen before and after each cycle.
■ Removing accumulated lint:
From inside the dryer cabinet:
Lint should be removed every 2 years or more often, depending
on dryer usage. Cleaning should be done by a qualied person.
From the exhaust vent:
Lint should be removed every 2 years, or more often,
depending on dryer usage.
■ Keep area around dryer clear and free from combustible
materials, gasoline, and other ammable vapors and liquids.
■ Keep dryer area clear and free from items that would
obstruct the ow of combustion and ventilation air.
If dryer does not operate, check the following:
■ Electrical supply is connected.
■ Circuit breaker is not tripped or house fuse is not blown.
■ Door is closed.
■ Controls are set in a running or “on” position.
■ START button has been pushed rmly.
■ For gas dryers, check that gas supply shut-off valves are set
in open position.
ELECTRONIC CONTROL SETUP ELECTRONIC CONTROL SETUP
INSTRUCTIONS (NON-COIN/COIN INSTRUCTIONS (NON-COIN/COIN
MODELS)MODELS)
GENERAL USER INFORMATIONGENERAL USER INFORMATION
BLANK DISPLAY –
This condition indicates the dryer is
inoperative. Enter set-up mode to view diagnostic code.
“0 MINUTES” SHOWING IN DISPLAY –
This indicates the previous cycle is complete or a machine reset
was performed. Opening the door(s) will restore the display to the
Vend Price or Available state.
Factory Default Settings – Dryer is programmed at the factory
as follows:
5 minutes dry time/quarter (coin 1)
$1.50 dry price (xed cycle with top off – Coin Models)
$0.00 dry price (xed cycle – Non-Coin Models)
WARM START (after power failure) – A few seconds after power
is restored, if a cycle was in progress at the time of the power
failure, "RESELECT CYCLE" will flash in the display, indicating a
button needs to be pressed to restart dryer.
There are four (4) types of dryer pricing:
Fixed “Vend” Pricing
A dryer set up for “Fixed Cycle” operation can only accept
additional time accumulated by increments equal to the length
of a complete dry cycle. A maximum of 75 minutes may be
purchased; no additional credit is given for coins dropped with
75 minutes in the display.
Accumulator Pricing
If the price is set to one coin 1, then accumulator pricing
is in effect. Cycle time can be purchased one coin at a time
(Coin models) up to the maximum time of 75 minutes.
Fixed Cycle With Top Off Pricing
A dryer set to offer “Top Off” capability will allow time to be
added to an existing dry cycle in increments equal to the number
of minutes of dry time per coins, up to 75 minutes, regardless of
the cost required to start the dryer.
No credit is given for coins entered when the control is displaying
75 minutes.
IMPORTANT
Electrostatic Discharge (ESD)
Sensitive Electronics
ESD problems are present everywhere. ESD may damage
or weaken the electronic control assembly. The new control
assembly may appear to work well after repair is nished,
but failure may occur at a later date due to ESD stress.
■ Use an anti-static wrist strap. Connect wrist strap to
green ground connection point or unpainted metal in the
appliance.
-OR-
Touch your nger repeatedly to a green ground connection
point or unpainted metal in the appliance.
■ Before removing the part from its package, touch the
anti-static bag to a green ground connection point or
unpainted metal in the appliance.
■ Avoid touching electronic parts or terminal contacts;
handle electronic control assembly by edges only.
■ When repackaging failed electronic control assembly
in anti-static bag, observe above instructions.
