English
|
7
COMPONENTS
UNDERSTANDING THE STRING TRIMMER
See Figure 1 and the Component Table.
To reduce the risk of personal injury and product failure, read and understand the information in this user manual and the information
on the product labeling.
COMPONENT TABLE
INDEX NUMBER COMPONENT DESCRIPTION
1 Top handle Provides directional control and stability during use.
2 Auxiliary handle Provides additional comfort and stability during use.
3 Lock-out button Prevents the string trimmer from initiating operation accidentally.
4 Switch trigger Initiates operation when squeezed in conjuction with holding the lock-out
button. The switch trigger must be held throughout use or the string trimmer
will not operate.
5 Guard Provides protection from debris and contact with the trimming wire.
6 Spool housing Storage for the wire used during operation.
7 Battery pack housing Location of the battery pack for connection and disconnection to the unit.
Figure 1
