8
|
English
ASSEMBLY
REMOVING CARTON CONTENTS
WARNING
This product requires assembly. Do not attempt to operate this product if any items in the INCLUDED LIST
are already assembled when you remove the carton contents. These items are not assembled by the manufacturer and should
require customer assembly. Using an improperly assembled product can be hazardous and could result in serious personal injury.
• Carefully open the carton.
• Remove and inspect the carton contents. Verify that all the items in the INCLUDED LIST are present and undamaged.
• Recycle or dispose of the packaging materials properly.
INCLUDED LIST
ITEM QUANTITY
Auxiliary handle 1
Guard 1
Top handle 1
Spool housing 1
If any parts are missing, contact our service team at service@wpowereq.com or call 1-855-944-3571.
WARNING
Do not alter or modify this product unless instructed otherwise in this manual or by the manufacturer. Do
not use attachments or accessories that are not recommended for use with this product. Making unauthorized modifications and
using incompatible accessories can damage the unit and may void your warranty.
WARNING
Do not connect the string trimmer to the battery pack until assembly is complete. Failure to comply could
result in accidental starting and possible serious personal injury.
Figure 2
ATTACHING THE GUARD TO THE SPOOL HOUSING
1. See Figure 2. Remove the screw (1) from the spool housing. Keep the screw for use later.
2. See Figure 3. Attach the guard to the spool housing.
3. Align the markers on the guard (2) with the markers on the spool housing (1). Rotate the guard until the markers on the guard
are secured into place.
4. See Figure 4. With the guard (2) attached to the spool housing (1), secure the guard to the spool housing with the screw (3).
(a) underneath view of the
spool housing
Figure 3
Figure 4
