8
All oor nishes
1
Floor nish
2
Floor deck
Floor deck to be tted in line with manufacturer instructions.
3
Floor sensor
Location shown below; Must be recessed into the joist.
4
Pipe clips
Clipped into insulation layer at beginning, middle and end of the pipe turns.
5
Warmup 16mm PE-RT pipe
6
Aluminium diuser plates
Stapled to joists at 150mm spacings.
7
Insulation layer
Thickness in line with building regulations.
8
25 x 25mm battens
To support the insulation layer
9
Joists at 400mm centres
10
Flow and return pipes
*
Installed beneath the Tectora diuser plates, notched or through holes drilled in the
joists in line with building regulations.
*
Service pipes must be insulated within the joist space and supported at 300mm
intervals on horizontal runs and 500mm on vertical runs using pipe clips
Typical oor build-up
2
4
1
8
3
5
6
7
10
9
3
