22 Device Description EPSITRON®
787-1662 Electronic Circuit Breaker
Manual
Version 1.0.0
3.5.3 Technical Data for "Output"
Table 14: Technical data - "Output"
Nominal output voltage
2 x 24 VDC
Output nominal current (adjustable)
787-1662:
787-1662/0106-0000:
787-1662/0006-1000:
2 A, 3 A, 4 A, 6 A, 8 A, 10 A
1 A, 2 A, 3 A, 4 A, 5 A, 6 A
0.5 A, 1 A, 2 A, 3 A, 4 A, 6 A
Voltage drop between input and output
787-1662:
787-1662/0106-0000:
787-1662/0006-1000:
200 mV with maximum output current
120 mV with maximum output current
145 mV with maximum output current
Device initialization time
250 ms
Waiting period after an output channel
has been de-activated (cooling time)
787-1662,
787-1662/0106-0000:
787-1662/0006-1000:
500 ms (short circuit), 20 s (overload)
500 ms (short circuit), 10 s (overload)
Total power dissipation for output
current 2 x 10 A
787-1662:
787-1662/0106-0000:
787-1662/0006-1000:
5.5 W with maximum output current
2.5 W with maximum output current
2.5 W with maximum output current
Efficiency
99 %
Maximum load capacity per output
channel
787-1662,
787-1662/0106-0000:
787-1662/0006-1000:
greater than 50 … 620 mF
greater than 65 … 620 mF
Integrated fusing per output channel
15 A, slow
ON delay
Based on load:
minimum 50 ms, maximum 5 s
Recovery stability
maximum 35 V
Parallel connection of output channels
prohibited
Series connection of output channels
prohibited
Output terminals
WAGO-MULTI CONNECTION
SYSTEM (MCS), 721 Series
Connection: 0.08 mm² … 2.5 mm²
(maximum 1.5 mm² with insulated
ferrule)
