EPSITRON® Device Description 21

787-1662 Electronic Circuit Breaker

Manual

Version 1.0.0

3.5.2 Technical Data for "Input"

Table 13: Technical data - "Input"

Nominal input voltage

24 VDC

Input voltage range

18 ... 30 VDC

Maximum residual ripple/

ripple for the input voltage

3 % with resistive load

Required input voltage at which the

output channels are activated (activation

threshold)

20 V

Input voltage at which the output

channels are de-activated (trip

threshold)

18 V

Maximum continuous current for the

device

787-1662:

787-1662/0106-0000,

787-1662/0006-1000:

20 A

12 A

Maximum continuous current per I/O

module pole

40 A

Overvoltage protection

Suppressor diodes (33 V)

Zero-signal current for open-circuit

operation at 24 V

787-1662,

787-1662/0106-0000:

787-1662/0006-1000:

35 mA

32 mA

Power dissipation for open-circuit

operation at 24 V

787-1662,

787-1662/0106-0000:

787-1662/0006-1000:

0.84 W

0.77 W

Input modules

WAGO-MULTI CONNECTION

SYSTEM (MCS), 721 Series

Connection: 0.08 mm² … 2.5 mm²

(maximum 1.5 mm² with insulated

ferrule)

WAGO-MULTI CONNECTION

SYSTEM (MCS), 831 Series

Connection: 0.5 mm² … 10 mm²

(maximum 6 mm² with insulated

ferrule)
