EPSITRON® Device Description 23

787-1662 Electronic Circuit Breaker

Manual

Version 1.0.0

3.5.4 Technical Data for "Ambient conditions"

Table 15: Technical data - "Ambient conditions"

Ambient temperature range

-25 °C … +70 °C

Derating

787-1662:

787-1662/0106-0000,

787-1662/0006-1000:

no derating

Requisite minimum spacing

(top/bottom)

40 mm

Requisite minimum spacing

(lateral)

0 mm

3.5.5 Technical Data for "Signaling"

Table 16: Technical data - "Signaling"

LED

green/red/orange (per output channel)

Control Input S1

non electrically isolated 24 VDC input

(relative to the module 0 V input)

Voltage level "active high":

minimum 15 V, maximum 30 V

Voltage level "active low":

minimum 0 V, maximum 5 V

Jitter for pulse pattern: ±5 % or ±5 ms;

with the higher value applying.

Waiting period after pulse sequence

(low level): minimum 200 ms

Signal Output S2

24 VDC, active high, short-circuit proof

maximum current carrying capacity:

25 mA

Signal Output S3

24 VDC, active high, short-circuit proof

maximum current carrying capacity:

25 mA

Control and Signaling Terminals

(S1, S2, S3)

WAGO-MULTI CONNECTION

SYSTEM (MCS), 721 Series

Connection: 0.08 mm² … 2.5 mm²

(maximum 1.5 mm² with insulated

ferrule)
