42
OPERATING MANUAL
VERSION 02/2018 ORDER NUMBER DOC 2366717
5.7.4 SPRAYING PROCEDURE FOR FLAT JET AIR ATOMIZING
In this process, the spray product is fed to the nozzle at a pressure of 0.05–0.2 MPa; 0.5–2 bar;
7–29 psi. The atomizing air at approx. 0.25 - 0.4 MPa; 2.5 - 4 bar; 36 - 58 psi produces a soft
spray jet, which largely eliminates the problem of overlapping boundaries at the edges.
The shaping air allows modication of the spray jet. There are various nozzles and air caps
available as accessories for the respective spray product and the discharge quantities.
B_04743
Shaping air
Atomizing air
Spray product
Spray angle
Air cap Spray pattern
Advantages
– Large range of adjustment of the spray jet
– Thin layers
– Uniform coating thickness
– Perfect nish
5.7.5 THE ELECTROSTATIC EFFECT
The in-system electrically loaded paint particles atomized by the spray gun are transported
to the grounded object by kinetic and electrostatic energy where they adhere, nely
distributed on the object being sprayed.
B_01893
Paint particle
Object to be sprayed is conductive
and grounded
Advantages
– Very high application eectiveness
– Low over spray
– Coating of entire circumferences due to the electrostatic eect
– Savings in working time
