41
OPERATING MANUAL
VERSION 02/2018 ORDER NUMBER DOC 2366717
5.7.3 SPRAYING PROCEDURE FOR ROUND JET AIR ATOMIZING
In this process, the spray product is fed to the nozzle with a pressure of approx. 0.05–0.2 MPa;
0.5–2 bar; 7–29 psi. The atomizing air at approx. 0.25 - 0.4 MPa; 2.5 - 4 bar; 36 - 58 psi
produces a soft spray jet, which largely eliminates the problem of overlapping boundaries
at the edges.
B_04742
Spray pattern
Union nut
Spray product
Atomizing air
Advantages
– Thin layers
– Uniform coating thickness
– Perfect nish
Nozzle selection
There are various round jet nozzles available as accessories for the respective spray product
and the discharge quantities:
– AWR 5000 with a xed spray jet width. Several nozzles and air caps sizes.
– EAWRV 5000 with a variable spray jet width.
