34
OPERATING MANUAL
VERSION 02/2018 ORDER NUMBER DOC 2366717
7 Push button "High voltage"
For activating the function.
The high voltage is set with the control dial (2) and is indicated in the LED display (27).
– Adjusting range: 5–70 kV
– Resolution: 1 kV
8 Illuminated display: "High voltage"
9 Regulator "Pump pressure"
Pressure regulator for pump pressure.
– Adjusting range 0–1.0 MPa; 0–10 bar; 0–145 psi.
10 Regulator "Product pressure"
Controls the product pressure regulator (option).
– Adjusting range 0–1.0 MPa; 0–10 bar; 0–145 psi.
11 Regulator "Atomizing air"
Pressure regulator for air supply (shaping and atomizing air) to the spray gun.
– Adjusting range 0–1.0 MPa; 0–10 bar; 0–145 psi.
12 Pressure gauge "Atomizing air"
Air pressure display for the spray gun.
– Display range 0–1.0 MPa; 0–10 bar; 0–145 psi
13 Pressure gauge "Product pressure"
Pressure display for the product pressure (if option product pressure regulator).
– Display range 0–1.0 MPa; 0–10 bar; 0–145 psi
14 Pressure gauge "Pump pressure"
Display for pump pressure.
– Display range 0–1.0 MPa; 0–10 bar; 0–145 psi
15 Push button "Recipe 1"
16 Illuminated display: "Recipe 1"
Illuminates if recipe 1 is used.
17 Push button "Recipe 2"
18 Illuminated display: "Recipe 2"
Illuminates if recipe 2 is used.
19 Push button "Recipe 3"
20 Illuminated display: "Recipe 3"
Illuminates if recipe 3 is used.
