Technical Manual
WDGA with IO-Link
4 - IO-Link
© Wachendorff Automation GmbH & Co. KG
26
4.6 Switching Signal Channel (CAM)
• Before changing the sensor profile, make sure that you reset
the parameters of the switching signal channel.
4.6.1 Single Point
In Figure 4.1 and Figure 4.2 the 'switching' behaviour of the Single Point mode is
shown. The switching state changes when the measured value exceeds or falls below
the value set in SP1. If a hysteresis has been set, this is also considered as shown in
the illustrations. SP2 is ignored in single point mode.
Figure 4.1: Single Point mode 1
Figure 4.2: Single Point mode 2
