Technical Manual
WDGA with IO-Link
4 - IO-Link
© Wachendorff Automation GmbH & Co. KG
23
used to adjust the
position value so that an
existing gear is taken into
account. -The total
resolution for this function
is limited to 20 bits (max.
1,048,576 steps) - The
revolution resolution has
no relevance for this
function; the 16-bit raw
resolution is always used.
Example rotary table:
Gear encoder: 12 teeth
Driven rotary table: 250
teeth
One rotation of the rotary
table should be mapped
to 100,000 steps. If the
driven rotary table rotates
once, the rotary encoder
shaft rotates 250/12, i.e.
20.8333 times.
The following setting
must be selected here:
Gear ratio numerator: 12
Gear ratio denominator:
250 Total resolution:
100000
1
Gear Ratio
Numerator
RW
UINT16
Counter
2
Gear Ratio
Denominator
RW
UINT16
Denominator
00BD
0
Position Filter
RW
UINT16
Number of average
values for the item value.
This value should only be
changed after intensive
consultation with the
support team.
Default: 48
1170
0
Velocity Value
RO
INT32
Speed of the shaft of the
encoder in increments
1171
0
Velocity Factor
RW
RecordT
1
Velocity factor
enable
RW
Boolean
(De)activate speed
factorization.
If factorization is
deactivated, the
numerator and
