Technical Manual
WDGA with IO-Link
4 - IO-Link
© Wachendorff Automation GmbH & Co. KG
22
00C2
Measurement
Preset
RW
UINT64
The preset value is
subject to scaling and can
be reset again and again.
With a preset, the current
position value is adapted
to the index stored in it.
System command 0xE0
must be executed to
perform the preset.
00C3
Measurement
Output
Characteristics
RW
INT8
Counting direction of the
position value with a view
of the shaft.
0 = CW
255 = CCW
00C4
Measurement
Hysteresis
RW
UINT8
Hysteresis of the position
value.
This value may only be
changed after intensive
consultation with Support.
Default = 4
0202
0
Measurement
Range
RO
RecordT
Working range of the
device
1
Measurement
Range - Lower Limit
RO
UINT64
Minimum position value
2
Measurement
Range - Upper Limit
RO
UINT64
Maximum position value
00FE
Device discovery
timeout time
RW
UINT16
Defines the duration of
the system command
0xAF (device discovery).
1160
0
Position Value
RO
UINT64
Current position of the
encoder
1161
0
Operation Mode
RW
UINT8
Defines the mode of the
position value calculation.
0 = no scaling
1 = scaling mode
2 = gear ratio mode
1162
0
Position Scaling
RW
RecordT
1
Measuring Units per
Revolution
RW
UINT32
Singleturn resolution of
the device
2
Total Measuring
Range
RW
UINT64
Multiturn resolution of the
device
1163
0
Position Gear Ratio
RW
RecordT
If the operation mode = 2,
the gear ratio is activated.
The two gear ratio
parameters, numerator
and denominator, can be
