movement and minimize device-generated vibrations. Its construction is shown in Fig. A-C on p. 2:
Fig. A: 1. Switch (on/off)
d) Check grinding wheels before each use. Grinding wheels
2. Butterfly nut
should be properly fixed and should allow for free
movement. Carry out a no load test run at its maximum speed
3. Machined object support
for at least one minute. Do not use damaged or vibrating
4. Grinding wheel
grinding wheels. Damaged grinding wheels can break resulting in
5. Anti-spark guard
serious injuries.
6. Anti-spark guard fixing
e) Children are not allowed to operate the device under any
7. Base mounting holes
circumstances.
Fig. C: 8. Fixing holes
9. Side guard
APPLICATIONS:
10. Retaining nut
The bench grinder is intended for dry rough and fine grinding of metals,
11. Pressure flange
plastics and other materials provided appropriate grinding wheel is
used.
12. Paper washer
The tool is designed for minor grinding jobs such as: processing and
13. Spindle
sharpening knives, scissors, drill bits, wood and stone chisels, cold chisels
14. Grinding wheel guard
etc.
It is absolutely prohibited to use the tool in other applications.
Despite using the tool according to its intended application it is
impossible to eliminate certain residual risk factors. Considering the tool
construction the following risks may occur when operating the tool:
- Touching the abrasive wheel in its unguarded area.
- Throwing back grinding wheel parts by centrifugal force.
- Throwing back machined object or its fragment.
- Hearing loss if no necessary hearing protection is used.
- Cracking/breaking the grinding wheel.
- Harmful dust emission when dry grinding indoors.
THE SET INCLUDES:
Bench grinder -1 piece
Multi-grain grinding wheel - 1 piece
Fine grinding wheel - 1 piece
Anti-spark guards with fixings -2 pieces
Machined object supports with fixings - 2 pieces
User's manual - 1 piece
Warranty card - 1 piece
CONSTRUCTION:
The bench grinding machine is driven by a single-phase electric motor
and is a Class I device – wall outlets and extension cables must be
equipped with an earthing conductor/terminal.
Each application of the tool not in line with the intended use as specified
below is strictly forbidden and makes the warranty terms null and void.
The manufacturer shall not be held responsible for possible
consequential damage that may arise due to or in connection with such
application.
Any modifications of the tool by the user relieve the manufacturer from
responsibility for any damage and injuries to the user and the
surroundings.
Application of the tool in accordance with the intended use also refers to
its maintenance, storage, transportation and repairs.
Defective electric tools can be handed over for repairs exclusively to
service workshops appointed by the tool manufacturer. The tools
supplied from electric grid shall be repaired exclusively by authorized
electricians.
SPECIFICATIONS:
S2 30 min – interrupted operation, rated operation time 30 min.
NOTE! After 30 minutes of constant load operation stop using the machine
and allow it to cool down completely.
PREPARING FOR OPERATION:
After unpacking the product check whether all components are present
and install all parts supplied separately by following the assembly
instructions.
NOTE: Before you start any installation or maintenance/adjustment
ź
always make sure that the machine is disconnected from the mains.
ź
n Positioning the machine
ź
To ensure operation safety, fix the grinding machine to a flat and stable
ź
working surface (e.g. a workbench).
ź
Place the grinder on a stable horizontal surface (table, bench) in an area
ź
providing free access and safe operation. Using the base mounting holes
ź
(7) install the machine on the bench securely with four fixing bolts. Bolts
length depends on the bench top thickness.
n Installing the machined object supports
Machined object supports (3) should be installed as shown in Fig. A2,
p.2.
Rated voltage 230 V
Rated frequency 50 Hz
Power consumption 200 W
No load maximum speed 2950 rpm
Grinding wheel dimensions
(max. diameter х thickness x hole diameter)
Grinding wheel granularity 1/2 36/60
No load peripheral speed 23 m/s
Operation cycle S2 30 min
Equipment Class
Weight 8,5 kg
Sound pressure level (LpA) 62,6 dB(A), ±3dB(A)
Sound power level (LpW) 75,6 dB(A), ±3dB(A)
I
150 x 16 x 12,7mm
