7
and three LEDs mean full battery.Charge the battery fully before use.
Charger VJ1LD
The first charging procedure using VJ1LD should last at least 1 hour (2.0Ah
VJ2AK battery), or 2 hours (4.0Ah VJ4AK battery).
1. Press the battery lock button (7) and take the battery (6) out of the drill
driver (see Fig. B).
2. ).Connect the battery (6) to the charger (10) (see Fig.C
3. Connect the charger plug to a mains socket (220–240 V, 50 Hz).
n Battery charging indicator
A green LED light indicates that the charger is connected to a power source.
After the battery is connected, the red LED is on to indicate charging.
When the battery is fully charged, the red LED goes off and the green LED is
on.
After charging, disconnect the charger and remove the battery.
NOTE! The battery may get slightly hot when charging. This is not a
malfunction.
The lithium-ion battery can be charged at any moment, without detriment
to its life. Interrupting the charging process does not entail a risk of
damaging the battery cells.
IN USE:
n Turning on/off
The switch (9) has fluid rotation speed adjustment built-in.
Press the switch to activate the power tool. The rotation speed will increase
the further the switch is pushed. To stop the power tool, release the switch.
n Choosing rotation direction (see Fig. E)
The driver can work with clockwise (right) or counter-clockwise (left)
rotation.
- to select clockwise rotation, move the clockwise/counter-clockwise slider
(4) to the left (looking from the back of the driver),
- to select counter-clockwise rotation, move the clockwise/counter-
clockwise slider (4) to the right (looking from the back of the driver),
When the rotation direction switch is in the middle position, the On/off
switch(9) is locked.
For drilling and driving screws in, clockwise operation should be selected. For
taking out the drill bit, removing a stuck drill bit, or unscrewing screws,
counter-clockwise operation should be selected.
n Choosing torque (Fig. F)
The driver is equipped with a ring (2), which can be used for setting the
toque when driving screws. The ring has 21 settings, from 1 to 20, and a
drilling setting.
Using a given setting (from 1 - 20) means that the clutch is set to an assigned
toque. This makes it possible to prevent a screw from being driven too far or
being damaged. Different torques should be used for different screws and
materials.
Always start with a low torque and increase gradually until the desired result
is achieved.
n Shifting gear (Fig. A)
The gear shifter (3) makes it possible to choose 2 rotation speed ranges.
Gear I: Used for driving and unscrewing screws.
Gear II: Used for drilling.
CAUTION: Do not change the position of the gear shifter (3) during tool
operation as this may damage the gear box. Always allow the tool to come to a
full stop before changing the setting of the gear shifter.
If the gear shifter does not move all the way, move the drive spindle slightly.
n Changing the chuck (Fig. G)
1. Disconnect the battery (6) from the driver.
2. Open the chuck as much as possible (1)
3. Using a PH 2 (Philips No.2) screwdriver, rotate the fixing screw of the
chuck clockwise (CAUTION! Left-thread). To free a seized bolt hit is
gently on its head.
4. Unscrew the chuck of the drill/screwdriver counter-clockwise (looking
from the point of view of the chuck).
CAUTION: A jammed keyless chuck (1) can be released by inserting the
short end of a hex key in the chuck and lightly tapping the longer arm of the
key (see Fig.D).
5. To attach the chuck, screw it onto the drive spindle clockwise and secure
by screwing in the fixing screw counter-clockwise using a PH 2
screwdriver (No.2 Philips).
AUXILIARY COMPONENTS:
ź The practical fastener (5) can be used for attaching the drill-driver on the
user's belt, both for right-hand and left-hand dominant users.
ź The drill/driver is equipped with an auxiliary light (10) for the area of
drilling/driving, which turns on after the appropriate switch (9) is
pushed.
n Installation and removing drills to/from the keyless chuck
CAUTION: Disconnect the battery from the driver or put the rotation direction
switch (4) in the middle position to secure the machine from being started by
mistake, which could in turn cause harm to the user.
When the tool trigger (9) is released the drill chuck is locked. It enables
quick, easy and convenient replacement of a working tool installed in the
drill chuck. To remove a drill (or a working bit) from the drill chuck, rotate the
chuck ring anticlockwise to expand the opening of the chuck. Insert a new
drill (or a working bit) into the chuck and rotate the chuck ring clockwise to
secure the drill in the drill chuck.
Drills (or other working bits) must be moved to the full depth of the chuck
opening.
n Drilling boreholes
1. To drill deep boreholes carry out your job gradually, drill to lower
depths and remove the drill from the borehole from time to time to
remove borings from the borehole.
2. To drill large diameter boreholes it is recommended to start with
drilling a low-diameter borehole and then expand it to the desired
diameter. It prevents the tool from overloads.
3. When the drilling bit is seized during working switch immediately
tool off to prevent it from being damaged. Switch the rotations
direction to the anticlockwise rotations and then remove the drilling
bit from the borehole.
4. Keep the drill aligned with the axis of the borehole. The drilling bit
must be positioned perpendicularly to the surface of the machined
material. When the perpendicularity fails to be maintained the
drilling bit may be seized or broken or, under extreme circumstances,
the operator may be injured.
Rotation speed of the drill spindle is controlled by the force the power
switch is depressed with.
n Driving screws
It is recommended to drill the pilot borehole first. The pilot borehole must
be a little deeper and with a less diameter than the outer diameter of the
