22 23
IMPACT
®
4000
Auto-Shutoff Selection
The Impact
®
4000 offers two Auto-Shutoff options: 1 minute and 3 minutes. It is also possible to turn off
the Auto-Shutoff feature. Once you have made your desired selection, return to the Settings Menu.
Visible Laser Selection
The Impact
®
4000 comes equipped with a Visible Laser to be used for zeroing the rangefinder. The Visible
Laser Switch must be enabled on the side of the rangefinder using the included Torx
®
T-10 Tool to function.
If the Visible Laser is ON, the red alignment laser will turn on. The use of the Visible Laser is only permitted
for zeroing. No range or ballistic solutions can be calculated while the Visible Laser is ON. Return to the
Settings Menu. Turning the Visible Laser Setting to OFF will re-enable ranging functions of the device.
Reset Selection
The Reset screen can be used to restore the Impact
®
4000 to factory
settings. Select “Erase All Data & Reset” to reset the device. Press
the “Setting” button to return to the Main Menu and continue on to
Connected Devices.
Note: This will clear your range cards, ballistic profiles, and all other
selections made. If you wish to save a copy of your range cards and
profiles prior to performing this step, make sure to sync your device with
the GeoBallstics
®
App.
CONNECTED DEVICES
The Impact
®
4000 can connect with the GeoBallistics
®
App for
quick customization and to the included Bluetooth
®
Remote for
easy adjustments without leaving the shooting position via the
Vortex Relay
™
Network. To manage connected devices, navigate to
and select “Connected Devices” from the Main Menu.
Note: The Impact
®
4000 can operate as a stand-alone device. Connection
to other devices such as the GeoBallistics
®
App and the Bluetooth
®
Remote
are not required.
Devices
The Devices screen allows you to view, add, or remove devices and connect your Bluetooth
®
Remote to the
devices you’d like for it to control.
View
On the View screen, you can view which devices are currently
connected via the Vortex Relay
™
Network. To show up on the
network, the devices must be previously added and turned on.
When you select a device, you can see the latest firmware and
software information by pressing the “Right Arrow” button.
Note: A network is a group of devices and mobile applications that
communicate to each other. Devices can only be connected to one network
at a time.
Note: On the Range Ready screen, the Bluetooth
®
icon will change to a number to indicate how many devices are on
the network. A “1” indicates that the Impact
®
4000 is the only device on the network. A “4” would indicate that three
other devices are on the network with the Impact
®
4000.
