IMPACT
®
4000
Building a Range Card
Line up your riflescope to your target and press the “Measure” button to range. The measured range will
show up as A. You can change this range until you are satisfied with the distance by pressing the “Measure”
button to range again or changing it manually by pressing the “Right Arrow” button to select the range and
adjust the distance using the up and down arrow buttons. If you are satisfied with your range, move onto the
next target by pressing the “Down Arrow” button to move to letter B. Continue these steps until all the
targets are entered.
HCD MODE BAL MODE LOS MODE
To save the Range Card, press the “Settings” button and select
“Yes” when asked to save changes.
Note: The Range Card will save the target distance, inclination, and
direction. If you update your wind or weather parameters, your range
card ballistic solutions will automatically update accordingly.
To turn OFF the Range Card, press the “Settings” button to return the Main Menu, select “Setup”, toggle
to and select “Range Card” and toggle to and select “OFF”. Return to the Main Menu and continue to
adjust the Impact
®
4000 Settings.
SETTINGS MENU
Changing Settings on the Impact
®
4000
The Impact
®
4000 is factory set to Brightness Level 3, Standard Units, Auto-Shutoff set to 3 minutes and
the Visible Laser set to OFF.
To Change Settings:
Press the “Settings” button to open the Main Menu. Navigate to and
select “Settings” to open the Settings Menu. In the Settings Menu,
you can access Backlight, Compass, Units, Auto-Shutoff, and Visible
Laser settings. This menu is also where you can reset your device to
factory settings.
Backlight Selection
Choose Between Five Brightness Settings
The Impact
®
4000 features five Backlight brightness settings.
Toggle through the five settings and select your desired brightness
level. Return to the Settings Menu.
Note: This adjusts the brightness of the Backlight. To turn the Backlight
ON/OFF, press the “Backlight” button under the Display Screen on the
Impact
®
4000.
Compass
The Impact
®
4000 compass needs to be calibrated during initial
setup and should be re-calibrated every time you significantly
change location, typically 30 miles or more. Calibrate your Impact
®
4000 outside and away from large metal structures or objects.
For instructions on how to calibrate your Impact
®
4000 see the
“Calibrating the Compass and Inclinometer” section on pages 9-11.
Note: You need to remove the Impact
®
4000 from your rifle before calibrating.
Unit Selection
The Impact
®
4000 offers the selection of standard or metric units. This will set all applicable Riflescope
Units, Weather Units, and Distance Units to that unit of measure. To customize each unit individually,
navigate to and select “Custom”. Press the “Right Arrow” button to open the Custom screen, where
you can edit Riflescope Units, Weather Units, and Distance Units independently. To change the unit of
measure, navigate to the unit you’d like to change, press the “Right Arrow” button to select the current
unit of measure, then use the Up and Down Arrow Buttons to toggle through the unit options. Once you
have selected your desired unit of measure, press the “Left Arrow” button to return to the list. Repeat
until all units are set to your preferences. Return to the Settings Menu to adjust the Auto-Shutoff settings.
