8. Baseplate cover
9. Baseplate
10. Guide roller
11. Chip break protection
12. Guard
13. Clamping lever
14. Wing bolts for parallel guide
15. Hex key
16. Chuck
17. Saw blade
18. Bolt for baseplate
19. Parallel guide
20. Dust outlet
21. Cutting mark
22. Selector for dust blowing/extraction
23. Battery LED indicators button
24. Battery LED indicators
25. Charger
26. Charger LED indicators
27. Vacuum cleaner adapter
28. Vacuum cleaner hose
3. ASSEMBLY
Before any work on the power tool, remove
the battery.
The battery must be charged before first use.
Inserting the battery into the machine (Fig. A, G)
Ensure that the exterior of the battery is
clean and dry before connecting to the
charger or machine.
1. Insert the battery (4) into the base of the machi-
ne as shown in Fig. G.
2. Push the battery further forward until it clicks
into place.
Removing the battery from the machine (Fig. A, G)
1. Push the battery unlock button (5)
2. Pull the battery out of the machine like shown
in Fig. G.
Checking the battery charging status (Fig. I)
• To check the battery charge status, push the
button (23) on battery shortly.
• The battery has 3 lights indicating the charge
level, the more lights that burn, the more char-
ge the battery has left.
•
When the lights are not burning it means the bat-
tery is empty and must be charged immediately.
Charging the battery with the charger (Fig. I)
1. Take the battery (4) from the machine.
2. Turn the battery (4) to upside down position and
slide it onto the charger (25) as shown in Fig. I.
3. Push the battery until it is fully pushed into the
slot.
4.
Plug the charger plug into an electrical outlet and
wait for a while. The LED indicators on the charger
(26) will lighten up and show the charger status.
The charger has 2 LED indicators (26) which indi-
cate the status of the charging process:
Red LED Status Green LED status Charger status
Off Off No power
Off On
Standby mode:
- No battery is
inserted or,
- Battery inserted
but charging has
finished
On Off
Battery charging in
progress
• Fully charging the 2Ah battery may take up to
35 minutes.
• Fully charging the 4Ah battery may take up to
60 minutes.
After the battery is fully charged remove the char-
ger plug from the outlet and remove the battery
from the charger.
When the machine is not being used over a
longer period of time it is best to store the
battery in charged condition.
Replacing the saw blade (Fig. A, C)
When mounting the saw blade, wear
protective gloves. Danger of injury when
touching the saw blade.
Only use saw blades that correspond with
the characteristic data given in the
operating instructions.
