8
EN
WWW.VONROC.COM
Model No. CD802AA
Charger input 220-240V, 50Hz 0.4A
Charger output 21V
2.5A
Charging time 2Ah battery 60 minutes
Charging time 4Ah battery 120 minutes
Recommended batteries CD828AA, CD829AA
Weight 0.36 kg
Wear hearing protection.
Only use the following batteries of the VONROC
POWER 20V battery platform. Using any other
batteries could cause serious injury or damage the
tool.
CD828AA 20V, 2Ah Lithium-Ion
CD829AA 20V, 4Ah Lithium-Ion
The following charger of the can be used to charge
these batteries.
CD802AA Quick charger
The batteries of the VONROC POWER 20V battery
platform are interchangeable with all the VONROC
POWER 20V battery platform tools.
Vibration level
The vibration emission level stated in this instruc-
tion manual has been measured in accordance
with a standardised test given in EN 62841; it may
be used to compare one tool with another and as
a preliminary assessment of exposure to vibration
when using the tool for the applications mentioned;
- using the tool for different applications, or with
different or poorly maintainted accessories,
may significantly increase the exposure level
- the times when the tool is switched off or when
it is running but not actually doing the job, may
significantly reduce the exposure level.
Protect yourself against the effects of vibration by
maintaining the tool and its accessories, keeping
your hands warm, and organizing your work patterns.
DESCRIPTION
The numbers in the text refer to the diagrams on
page 2-3.
1. On/off switch
2. Mounting point for accessories
3. Grip
4. Quick change lever
5. Battery
6. Battery unlock button
7. Dust extraction adapter
8. Sanding pad
9. Battery LED indicators button
10. Battery LED indicators
11. Charger
12. Charger LED indicators
13. Speed adjustment wheel
3. ASSEMBLY
Before any work on the power tool, remove
the battery.
The battery must be charged before first use.
Inserting the battery into the machine (Fig. C)
Ensure that the exterior of the battery is
clean and dry before connecting to the
charger or machine.
1. Insert the battery (5) into the base of the
machine as shown in Fig. D.
2. Push the battery further forward until it clicks
into place.
Removing the battery from the machine (Fig. D)
1. Push the battery unlock button (6).
2. Pull the battery out of the machine like shown
in Fig. D.
Checking the battery charging status (Fig. E)
• To check the battery charge status, push the
button (9) on battery shortly.
•
The battery has 3 lights indicating the charge
level, the more lights that burn, the more charge
the battery has left.
•
When the lights are not burning it means the bat-
tery is empty and must be charged immediately.
Charging the battery with the charger (Fig.E)
1. Take the battery (5) from the machine.
2. Turn the battery (5) to upside down position and
slide it onto the charger (11) as shown in Fig. D.
3. Push the battery until it is fully pushed into the slot.
4. Plug the charger plug into an electrical outlet and
wait for a while. The LED indicators on the charger
(12) will lighten up and show the charger status.
