1
Figure 4.3.2-2 CV mode operation interface
There are two ways to set the output voltage (CV mode):
Mode one:
1. Press MODE and rotary the knob to select CV mode, press Enter to save.
2. Press Enter key to edit the voltage setting, use the numeric 0-9 softkey to
set desired voltage. Press Enter key to save voltage setting, or turn the
knob to adjust directly to the set value.
3. Press ON/OFF key to output the setting voltage.
Mode two:
1. Press CV , at the same time, the user interface will switch into CV mode.
2. Press Enter key to edit the voltage setting, use the numeric 0-9 softkey to
set desired voltage. Press Enter key to save voltage setting, or turn the
knob to adjust directly to the set value.
3. Press ON/OFF key to output the setting voltage.
In constant voltage mode, the user can also set the following parameters.
Operation steps:
1. Press CONF to enter PARAM.(PARAMETER SETUP)
2. Set I_LIM (maximum working current)
3. Set V_RANGE, I_RANGE (voltage/current range)
