Front Panel Description and Functions cont...
7
15. PREV / NEXT buttons - These buttons are used to either go back to a PREVIOUS track or advance the NEXT track on a disc during
playback.
16. B-SCAN / F-SCAN buttons - These buttons are used to SCAN either BACKWARD or FORWARD through tracks on a disc during
playback. NOTE: Using the B-SCAN and F-SCAN buttons during the playback of a CDG disc while performing Karaoke is not
recommended as it will cause the onscreen lyrics to scramble.
17. MUTE button - Press this button to SILENCE audio playback. Press a second time to return to audio playback.
18. AUDIO button - This button will cycle between three AUDIO PLAYBACK MODES: STEREO, LEFT/LEFT and RIGHT/RIGHT. In
STEREO mode, audio playback is standard L/R audio. In L/L mode, the right channel is removed and replaced with a duplicate left
channel. In R/R mode, the left channel is removed and replaced with a duplicate right channel.
19. REPEAT button - Press once to access the REPEAT selection window, press twice to select TRACK REPEAT mode and press a third
time to select DISC REPEAT mode.
20. DISC tray - This tray is used for inserting and removing discs. The DISC TRAY is operated with the EJECT button.
21. EJECT button - This button is used to OPEN/CLOSE the DISC tray.
22. VOCAL CANCEL button - This feature is used to cancel out the lead vocal layer on a multiplex format CD+G or VCD disc. In
order for this feature to work, the disc must be multiplex formatted. To activate, press the VOCAL CANCEL button once to remove
the lead vocal layer. Press a second time, and the lead vocal layer will be reestablished. NOTE: If you try to utilize this feature while
a standard or non-multiplex disc is playing, it will not work as this feature is designed to work with multiplex discs only.
23. VOCAL PARTNER button - This feature acts very similar to the vocal cancel feature, but with an added voice activation feature that
acts like a vocal "auto-pilot". When you enable the VOCAL PARTNER feature, the lead vocal layer will be removed as long as you are
singing into the microphone. When you stop singing into the microphone, the lead vocal layer will automatically be added back into
the music. To activate VOCAL PARTNER, press button once. To remove VOCAL PARTNER, press a second time. NOTE: If you try to
utilize this feature while a standard or non-multiplex disc is playing, it will not work as this feature is designed to work with
multiplex discs only.
24. MIC VOLUME control - This control is the Master MIC VOLUME level for all microphone output. Turn clockwise to
increase and counter-clockwise to decrease.
25. AV3 INPUT jacks (RCA) - These jacks are for connecting AUDIO/VIDEO OUTPUT from an external AV SOURCE. Connect an
RCA-style AV cable (R, W, Y) from these jacks to the AV OUTPUT jacks on your external AV device.
Front Panel
BASS TREBLE ECHO
MIC EFFECTS
REPEAT
DELAY
VOCAL
CANCEL
VOCAL
PARTNER
MIC1 MIC2 VOL1 VOL2
MIC VOLUME
GUITAR
VOL.
KEYBOARD
VOL.
HEADPHONES
VOL.
AV3 INPUT
PLAYER KEY CONTROLLER
b
#
MUSIC VOLUME
REPEAT
L/R
MUTE
F-SCAN
B-SCAN
NEXT
PREV
PBCSTOP
PAUSE
PLAY
EJECT
DIGITAL AUDIO
COMPACT
DIGITAL AUDIO
COMPACT
PRO DIGITAL ECHO
MULTI-FORMAT PLAYER/MIXING AMPLIFIER
INPUT
AV1
AV2
AV3
POWER
STANDBY
GIGMAN
DISC
EQ ON
EQ OFF
MUSIC EQ
60Hz
+12dB
-12dB
0dB
+12dB
-12dB
0dB
200Hz 400Hz
1KHz 3KHz
6KHz
16KHz
60Hz 200Hz 400Hz
1KHz 3KHz
6KHz
16KHz
15
16 17
18
19 28
21
22
23
24
25
26
30
29
27
20
33
34
31
32
35
36
CDG
