17/37
③ Subnet Mask: The Subnet Mask of the Encoder.
④ Gateway: The Gateway of the Encoder.
Note:
(1) If the IP mode is set to “Static”, you can manually set the IP Address,
Subnet Mask and Gateway as required. Then click “Apply”, the Encoder will
immediately reboot to take effect.
(2) If the IP mode is set to “DHCP”, it will search and be filled with the IP
Address assigned by the router automatically.
(3) If the Encoder is actually alive in the system but with incorrect network
segment settings, even though the Encoder is offline, its network settings
including IP address can be changed and set.
Hardware Usage
① CEC Pin Usage: Click the drop-down menu to set the CEC pin usage
(ARC/eARC/CEC/Off). After switching, the Encoder will immediately reboot
to take effect.
② ARC/eARC Return From: Click the drop-down menu to select a Decoder
for ARC/eARC audio return.
Note: Only Encoders with ARC/eARC function can perform this setting.
③ Capability of Amplifier On HDMI IN Port: It indicates the ARC capability
supported by the Amplifier.
Note: When the amplifier on HDMI IN port only supports ARC, and the TV
connected to the Decoder only supports eARC, the setting of “eARC Down
grade To ARC” on the Decoder needs to set “On” to achieve the audio path
working normally. The eARC downgrade of the Decoder will also apply onto
all Encoders that select this Decoder.
④ Network Interface Usage: Click the drop-down menu to set the network
port (Fiber/Copper).
Note: Only Encoders that integrate Copper and Fiber ports can perform this
setting.
