7
Home automation system push button control devices, KNX standard
Communication objects and ETS parameters
Continued
C = Communication; R = Read; W = Write; T = Transmission; U = Enable update
No. ETS name Function Description Length
Flag 1
C R W T U
2 Up key Multiple press - Value 2
(if set as “Push button” and "Switching module with several ob-
jects/Multiple presses” function) - to send a message at the sec-
ond event of multiple presses.
1bit/1byte/
2byte
X X X
2 Keys Dimmer control
(if set as “Switching module” and "Dimmer control” function) to
control a dimmed light
4 bit X X X
2 Keys Venetian blind ON/OFF
(if set as “Switching module” and "Roller shutters” function) to
stop a roller shutter or the movement of the slat
1 bit X X X
3 Up key Short sequence - Value 3
(if set as “Push button” and "Switching module with several ob-
jects/Sequence” function) - to send the third 1 bit or 1 byte se-
quence message on short press.
1bit/1byte X X X
3 Up key Multiple press - Value 3
(if set as “Push button” and "Switching module with several ob-
jects/Multiple presses” function) - to send a message at the third
event of multiple presses.
1bit/1byte/
2byte
X X X
4 Up key
ON/OFF state
ON/OFF state - short press
Roller shutter state
(if set as "Push button" and "Single push button dimming" func-
tion or " Switching module with several objects/Short-long press/
toggle" or "Roller shutter single push button control” function se-
lected) this object must be associated with the group with the
light “ON/OFF control” datapoint (relay or dimmer) or the roller
shutter "roller shutter up/down” datapoint to receive the ON/OFF
state of the associated load. If this is not the case, it will be unable
to manage light control or roller shutter operation.
1 bit X X X
4 Up key Multiple press - Value 4
(if set as “Push button” and "Switching module with several
objects/Multiple presses” function) - to send a message at the
fourth event of multiple presses.
1bit/1byte/
2byte
X X X
4 Up key Short sequence - Value 4
(if set as “Push button” and "Switching module with several ob-
jects/Sequence” function) - to send the fourth 1 bit or 1 byte se-
quence message on short press.
1bit/1byte X X X
5 Up key ON/OFF state - long press
(if set as "Push button" and "Switching module with several ob-
jects/Short-long press/toggle” function) - this object must be as-
sociated with the group with the light "ON/OFF control” datapoint
on long press to receive the ON/OFF state of the associated load.
If this is not the case, it will be unable to manage light control.
1 bit X X X
5 Up key Long sequence - Value 1
(if set as “Push button” and "Switching module with several ob-
jects/Sequence” function) - to send the first 1 bit or 1 byte se-
quence message on long press.
1bit/1byte X X X
6 Up key Long sequence - Value 2
(if set as “Push button” and "Switching module with several ob-
jects/Sequence” function) - to send the second 1 bit or 1 byte
sequence message on long press.
1bit/1byte X X X
7 Up key Long sequence - Value 3
(if set as “Push button” and "Switching module with several ob-
jects/Sequence” function) - to send the third 1 bit or 1 byte se-
quence message on long press.
1bit/1byte X X X
8 Up key Long sequence - Value 4
(if set as “Push button” and "Switching module with several ob-
jects/Sequence” function) - to send the fourth 1 bit or 1 byte se-
quence message on long press.
1bit/1byte X X X
9 upper LED State
To display an ON or OFF state on the LED with a colour (red,
green, blue, amber, white, cyan, magenta, RGB custom triple)
and the type selected during configuration (maximum brightness,
medium brightness, minimum brightness, OFF, rapid flashing,
slow flashing)
1 bit X X X
10 Down key Value to send
(if set as "Push button" and the "switching 1 object” function is
selected) - to send "ON/OFF/timed ON” messages.
1 bit X X X
10 Down key Sends value - short press
(if set as "Push button" and "Short/Long press” function) - to
send "Toggle/send ON/send OFF" messages with short press: if
used in Toggle mode, also associate the object of "ON/OFF state"
of the button in the same group as this object.
1 bit X X X
10 Down key Send forcing
(if set as “Push button” and " Switching module with several ob-
jects/Forcing” function) to send one of the forcing functions for
selection as "forcing On/forcing OFF/Forced disable"
2 bit X X X
10 Down key Send value - up
(if set as "Push button" and " Switching module with several ob-
jects/on the edge” function) to send one of functions for selection
as "ON/OFF on the rising edge" (pressing the button)
1 bit X X X
10 Down key Scenario - short press
(if set as "Push button" and " Switching module with several ob-
jects/Short-long press/call up or store scenario” function) to call
up or store a scenario on short press.
1 byte X X X
Continued
