8
Home automation system push button control devices, KNX standard
No. ETS name Function Description Length
Flag 1
C R W T U
10 Down key Send value - short press
(if set as "Push button" and " Switching module with several ob-
jects/Value” function) to send a value that can be set between 0
and 255 on short press.
1 byte X X X
10 Down key ON/OFF control
(if set as “Push button” and "Single push button dimming” func-
tion) to control a dimmed light
1 bit X X X
10 Down key Short sequence - Value 1
(if set as “Push button” and "Switching module with several ob-
jects/Sequence” function) - to send the first 1 bit or 1 byte se-
quence message on short press.
1 bit/1 byte X X X
10 Down key Multiple press - Value 1
(if set as “Push button” and "Switching module with several ob-
jects/Sequence” function) - to send the first 1 bit or 1 byte se-
quence message on short press.
1bit/1byte/
2byte
X X X
10 Down key Sends value - long press
(if set as "Push button" and "short/long press” function) - to send
"Toggle/send ON/send OFF" messages with long press: if used in
Toggle mode, also associate the object of "ON/OFF state" of the
button in the same group as this object.
1 bit X X X
10 Down key Venetian blinds / Stop
(if set as "Push button" and "Roller shutter single push button
control” function) - to stop the roller shutter on short press.
1 bit X X X
10 Down key Send value - long press
(if set as "Push button" and " Switching module with several ob-
jects/Value” function) - to send a value that can be set between 0
and 255 on long press.
1 byte X X X
11 Down key Dimmer control
(if set as “Push button” and "Single push button dimming” func-
tion) to control a dimmed light
4 bit X X X
11 Down key Send value - down
(if set as "Push button" and " Switching module with several ob-
jects/on the edge” function) to send one of functions for selection
as "ON/OFF on the falling edge (release the button)
1 bit X X X
11 Down key Send forcing
(if set as "Push button" and " Switching module with several ob-
jects/on the edge” function) to send one of functions for selection
as "ON/OFF on the falling edge (release the button)
2 bit X X X
11 Down key Scenario - long press
(if set as "Push button" and " Switching module with several ob-
jects/Short-long press/call up or store scenario” function) to call
up or store a scenario on long press.
1 byte X X X
11 Down key Short sequence - Value 2
(if set as “Push button” and "Switching module with several ob-
jects/Sequence” function) - to send the second 1 bit or 1 byte
sequence message on short press.
1 bit/1 byte X X X
11 Down key Multiple press - Value 2
(if set as “Push button” and "Switching module with several ob-
jects/Multiple presses” function) - to send a message at the sec-
ond event of multiple presses.
1bit/1byte/
2byte
X X X
11 Keys Dimmer control
(if set as “Switching module” and "Dimmer control” function) to
control a dimmed light
4 bit X X X
11 Keys Venetian blind ON/OFF
(if set as “Switching module” and "Roller shutters” function) to
stop a roller shutter or the movement of the slat
1 bit X X X
12 Down key Short sequence - Value 3
(if set as “Push button” and "Switching module with several ob-
jects/Sequence” function) - to send the third 1 bit or 1 byte se-
quence message on short press.
1bit/1byte X X X
12 Down key Multiple press - Value 3
(if set as “Push button” and "Switching module with several ob-
jects/Multiple presses” function) - to send a message at the third
event of multiple presses.
1bit/1byte/
2byte
X X X
13 Down key
ON/OFF state
ON/OFF state - short press
Roller shutter state
(if set as "Push button" and "Single push button dimming" func-
tion or " Switching module with several objects/Short-long press/
toggle" or "Roller shutter single push button control” function se-
lected) this object must be associated with the group with the
light “ON/OFF control” datapoint (relay or dimmer) or the roller
shutter "roller shutter up/down” datapoint to receive the ON/OFF
state of the associated load. If this is not the case, it will be unable
to manage light control or roller shutter operation.
1 bit X X X
13 Down key Multiple press - Value 4
(if set as “Push button” and "Switching module with several
objects/Multiple presses” function) - to send a message at the
fourth event of multiple presses.
1bit/1byte/
2byte
X X X
13 Down key Short sequence - Value 4
(if set as “Push button” and "Switching module with several ob-
jects/Sequence” function) - to send the fourth 1 bit or 1 byte se-
quence message on short press.
1bit/1byte X X X
Communication objects and ETS parameters
Continued C = Communication; R = Read; W = Write; T = Transmission; U = Enable update
Continued
