6
Home automation system push button control devices, KNX standard
Communication objects and ETS parameters
List of existing communication objects and standard settings
Continued
C = Communication; R = Read; W = Write; T = Transmission; U = Enable update
No. ETS name Function Description Length
Flag 1
C R W T U
2 PUSH BUTTON MODE
1 Up key Value to send
(if set as "Push button" and the "switching 1 object” function is
selected) - to send "ON/OFF/timed ON” messages.
1 bit X X X
1 Up key Sends value - short press
(if set as "Push button" and "Short/Long press” function) - to
send "Toggle/send ON/send OFF" messages with short press: if
used in Toggle mode, also associate the object of "ON/OFF state"
of the button in the same group as this object.
1 bit X X X
1 Up key Send forcing
(if set as “Push button” and " Switching module with several ob-
jects/Forcing” function) to send one of the forcing functions for
selection as "forcing On/forcing OFF/Forced disable"
2 bit X X X
1 Up key Send value - up
(if set as "Push button" and " Switching module with several ob-
jects/on the edge” function) to send one of functions for selection
as "ON/OFF on the rising edge" (pressing the button)
1 bit X X X
1 Up key Scenario - short press
(if set as "Push button" and " Switching module with several ob-
jects/Short-long press/call up or store scenario” function) to call
up or store a scenario on short press.
1 byte X X X
1 Up key Send value - short press
(if set as "Push button" and " Switching module with several ob-
jects/Value” function) to send a value that can be set between 0
and 255 on short press.
1 byte X X X
1 Up key ON/OFF control
(if set as “Push button” and "Single push button dimming” func-
tion) to control a dimmed light
1 bit X X X
1 Up key Short sequence - Value 1
(if set as “Push button” and "Switching module with several ob-
jects/Sequence” function) - to send the first 1 bit or 1 byte se-
quence message on short press.
1 bit/1 byte X X X
1 Up key Multiple press - Value 1
(if set as “Push button” and "Switching module with several ob-
jects/Multiple presses” function) - to send a message at the first
event of multiple presses.
1bit/1byte/
2byte
X X X
1 Keys ON/OFF
(if set as "Switching module" and the "Power on/off” function is
selected) - to send "On/Off” messages pressing the top/bottom
or bottom/top part respectively (direction set by the parameter)
on the double push button
1 bit X X X
1 Keys ON/OFF control
(if set as “Switching module” and "Dimmer control” function) to
control a dimmed light. The controls of the switching module can
be inverted using the parameter.
1 bit X X X
1 Keys Roller shutter Up/Down
(if set as “Switching module” and "Roller shutters” function) to
control the operation of a roller shutter. The controls of the switch-
ing module can be inverted using the parameter.
1 bit X X X
1 Up key Sends value - long press
(if set as "Push button" and "short/long press” function) - to send
"Toggle/send ON/send OFF" messages with long press: if used in
Toggle mode, also associate the object of "ON/OFF state" of the
button in the same group as this object.
1 bit X X X
1 Up key Venetian blinds / Stop
(if set as "Push button" and "Roller shutter single push button
control” function) - to stop the roller shutter on short press.
1 bit X X X
1 Up key Send value - long press
(if set as "Push button" and " Switching module with several ob-
jects/Value” function) - to send a value that can be set between 0
and 255 on long press.
1 byte X X X
2 Up key Dimmer control
(if set as “Push button” and "Single push button dimming” func-
tion) to control a dimmed light
4 bit X X X
2 Up key Send value - down
(if set as "Push button" and " Switching module with several ob-
jects/on the edge” function) to send one of functions for selection
as "ON/OFF on the falling edge (release the button)
1 bit X X X
2 Up key Send forcing
(if set as “Push button” and " Switching module with several ob-
jects/Forcing” function) to send one of the forcing functions for
selection as "forcing On/forcing OFF/Forced disable"
2 bit X X X
2 Up key Scenario - long press
(if set as "Push button" and " Switching module with several ob-
jects/Short-long press/call up or store scenario” function) to call
up or store a scenario on long press.
1 byte X X X
2 Up key Short sequence - Value 2
(if set as “Push button” and "Switching module with several ob-
jects/Sequence” function) - to send the second 1 bit or 1 byte
sequence message on short press.
1 bit/1 byte X X X
SWITCHING MODULE AND PUSH BUTTON FUNCTIONAL UNITS
3. Communication objects and ETS parameters
