Home automation system push button control devices, KNX standard

2. Devices

General characteristics

The devices are equipped with four or six independent buttons that can be used as ON/OFF controls and for controlling roller shutters and lights. The device is KNX Data Secure

and is equipped with a dedicated QR code to be used with ETS (version 5.5 and later) during conﬁguration. Especially:

• Art. 22581.x:

- 1 toggle operating two independent push buttons

- 2 RGB LEDs with conﬁgurable colour

• Art. 22582.x:

- 2 toggles operating four independent push buttons

- 4 RGB LEDs with conﬁgurable colour

• Art. 30583-01583-01583.AX:

- 4 independent pushbuttons

- 4 RGB LEDs with conﬁgurable colour

- built-in temperature sensor

• Art. 30588-01588-01588.AX:

- 6 independent pushbuttons

- 6 RGB LEDs with conﬁgurable colour

Functions

The push buttons can be used in two ways:

• Functions with independent push buttons:

- Sending ON, OFF, timed ON, forcing and toggle controls both on short press and on long press

- Switch ON and OFF on the rising edge and on the falling edge

- Calling up a scenario with a short press of the push button, calling up a second scenario or saving a scenario with a long press

- Sending cyclic or increasing/decreasing bit or byte sequences via short and long press

- Sending one or two values via short or long press of the push button

- Sending bit, byte or 2 byte controls via multiple close presses

- Roller shutter control

- Dimmer control

• Functions possible with push buttons and 2 associated channels:

- Switch ON and OFF

- Dimmer control

- Roller shutter control

For all three functions, the direction of the controls can be inverted.

• Temperature measurement (only for art. 30583-01583-01583.AX):

- Built-in sensor: measurement range from 0 °C to 40 °C, ±0.5 °C between 15 °C and 30 °C, ±0.8 °C at the extremes

- Adjustable temperature offset from -2 °C to 2 °C

- Cyclical transmission

- Send on change

The following can be set for the RGB LEDs:

- The colour each individual LED, either by choosing from a list or by setting the RGB coordinates using the ETS software

- Brightness or ﬂashing also using the ETS software

- The LED colours and brightness can be customised according to day/night time

- The LED colours and brightness can be customised according to load status
