BUILDING AUTOMATION

Parameter “Time mode for function OFF”

This parameter defines the off time of the fan. Options:

None

Switch delay

Minimum time

None: Execute immediately after receiving the control command to turn off the fan;

Switch delay: Delay off the fan, the OFF action after reset, will also be turned off after the delay, the delay time is set by the following parameter “Delay time

[1...65535] * 0.1s”;

Minimum time: The wind is removed for the shortest time. Only after this time can the fan be turned on again. The minimum closing time is set by the parameter

“Minimum time[1...65535]s”. If a message of the blower is received during the shortest off time, then it is necessary to wait until the period has passed before the

blower is executed. Note that the OFF action after reset is also the shortest time to consider.

• Parameter “Delay time [1..65535]*0.1s”

This parameter defines the time for the fan to be turned off. Options:

1...65535

• Parameter “Minimum time [1..65535]s”

This parameter defines the minimum time that the fan is off. Options:

1...65535

4.7.1.1 Parameter window “Fx: Auto.”

When the parameter window “Auto. operation function” setting interface in Figure 4.20 selects “Enable”, the interface for automatic operation is visible.

The interface of Figure 4.21 is used to set the automatic operation of level 1 fan speed, and the threshold can be defined. Automatically, the control value

of the fan speed comes from the bus, and one control value or two control values can be set in the function parameters. For example, in the fan coil

control system, only heating or cooling, at this time, the fan control only needs to set a control value. If there is heating in the system and there is cooling,

then the fan control setting two control values will be more appropriate.

Normal operation and automatic operation cannot occur at the same time, that is, after the automatic operation is activated by the object “Automatic

function”, if there are other operations (such as normal operation, forced operation, manual operation), the automatic operation will exit by itself, and the

object “Automatic function” is required. Activated again, the object “Status Automatic” reports whether the automatic operating status is active.

Fig. 4.21 Parameter window “Fx: Auto.”

Parameter setting description in the ETS
