BUILDING AUTOMATION

Parameter “Forced operation function”

This parameter is used to enable forced operation. Options:

Disable

Enable

Select “Enable”, the 1-bit communication object “Forced operation” is visible, the following two parameters are also visible, used to set the activation value of the

forced operation and the action of the forced operation.

• Parameter “Forced operation on object value ”

This parameter sets the value of the message used to activate the forced operation. Options:

0=Force/1=Cancel

1=Force/0=Cancel

0=Force/1=Cancel: When the object “Forced operation” receives the message value “0”, the forced operation is activated. When “1” is received, the forced

operation is canceled.

1=Force/0=Cancel: When the object “Forced operation” receives the message value “1”, the forced operation is activated. When “0” is received, the forced

operation is canceled.

• Parameter “Behaviour on Forced operation ”

This parameter defines how the fan behaves when a forced operation is performed. Options:

Unchange

OFF

Unchange: The fan speed of the fan remains unchanged

OFF: Turn off the fan;

ON: Turn on the fan.

The forced operation has the second highest priority, but is also affected by the minimum run time and delay switch set by the parameters below.

Parameter “Auto. operation function ”

This parameter is used to enable automatic operation of the fan. Options:

Disable

Enable

Enable: The parameter interface 4.21 is visible. At the same time, the following parameters will also affect the actions of automatic operation, such as delay switch

and minimum running time.

Parameter “Time mode for function ON”

This parameter defines the run time of the fan. Options:

None

Switch delay

Minimum time

None: Execute immediately after receiving the control command of the blower;

Switch delay: Delayed opening of the fan, ON action after reset, will also be delayed to open, the delay time is set by the following parameter “Delay time

[1...65535] * 0.1s”. If the fan object “Fan speed” receives the message “1” multiple times in succession, the delay time is timed according to the actual situation,

instead of counting from the last received message time;

Note: The ON action after resetting also needs to consider this delay time. After the delay is completed, turn on the fan.

Minimum time: The minimum running time of the fan can only be turned off after this running time has elapsed. The minimum running time is set by the parameter

“Minimum time [1...65535]s”. If a message to turn off the fan is received during the minimum running time, then it is necessary to wait until the period has passed

before the action of turning off the fan is performed.

• Parameter “Delay time [1..65535]*0.1s”

This parameter defines the time at which the fan is turned on after a delay. Options:

1...65535

• Parameter “Minimum time [1..65535]s”

This parameter defines the minimum run time after the fan is turned on. Options:

1...65535

Parameter setting description in the ETS
