BUILDING AUTOMATION

4.5.1.4 Parameter window “Cx: Safety”

The parameter window “Cx: Safety” setting interface is shown in Figure 4.18. Here, the safety operation function of the blinds is mainly set.

Fig. 4.18 Parameter window “Cx: Safety”

In this interface, the action that the blinds should perform after the Safety operation function of each output is triggered is set. The settings for each chan-

nel are relatively independent and do not affect each other.

Parameter “Safety operation 1/2 ”

This parameter is used to set whether to activate the Safety operation function of the blinds. Options:

Inactive

Active

When “Inactive” is selected, the security operation function will not be activated;

If “Active” is selected, the safety operation function is activated, the following parameters will be visible, the trigger condition can be set for the safety

operation function, and the corresponding communication object “Safety operation 1/2” will be enabled.

Parameter “Safety operation trigger value (Cancel safety is opposite of selection)”

This parameter is used to set the trigger value for the Safety operation function of the blinds. Options:

When set to “0”, if the communication object “Safety operation 1/2” receives a telegram with a logic value of “0”, the security operation will be triggered.

When the telegram “1” is received, the security operation will be canceled. At this time, the monitoring period of the Safety operation function is reset;

When set to “1”, if the communication object “Safety operation 1/2” receives a telegram with a logic value of “1”, a security operation will be triggered.

When the telegram “0” is received, the security operation is canceled. At this time, the monitoring period of the safety operation function is reset.

Parameter “position on safety operation 1/2”

This parameter sets the action that the blinds perform after the safe action is triggered. Options:

Unchange

Down

Stop

Parameter setting description in the ETS
