Parameter “The input x of Logic” (x = 1, 2)”

This parameter is used to enable input 1 and input 2. If enable, their communication objects “Logic 1” and “Logic 2” will be also visible. Options:

Disable

Enable

Parameter “Logic function type”

This parameter set logic function type, provided three standard logic operations: AND, OR, XOR, and a GATE function. Explanation of gate function: it will use

the next logic value as the enable mark of the previous logic. If the enable mark of the next logic is “1”, that means it is able to use the previous logic value as the

operation result. E.g. the value of input 1 is 1, that means the value of input 0 can be used as the operation result; if the value 2 is 1, that means the operation

value of input 0/1 can be used as the result. Options:

AND

XOR

GATE

Below result of logic operation is possible:

Logic function

Object values

Description

Input0(Switch) Input1 Result of Input 0/1 Input2 Output

AND

The result is 1 if both input values

are 1.

The result is 1 if one of both input

values is 1

XOR

The result is 1 if both input values

have a different value.

GATE

Closed

Open

Closed

Open

Closed

Open

Closed

Open

The input 0 of value is only allowed

through if the GATE (input 1 and input

2) is open. Otherwise the input0 of

value is ignored.

Note:

1. The value of the communication object “Logic 1” makes logic operation with “Switch” ﬁrstly, and then the result will makes operations with the value of

“Logic 2”, and the ﬁnal operation result as the ﬁnal output (close the contact with “1”, open it with “0”).

2. If an input is not enabled, the input is ignored.

3. If logical result needs to be negated, the ﬁrst negated, then the next step.

4, The signal can be passed if the GATE is open, otherwise it is ignored. For example, the input 0 of value is ignored when the GATE of input 1 is closed, and

the output is directly determined by the input 2.

Parameter “Result reverse”

This parameter defines whether negate the logical operation results. Negate it with “yes”, don’t with “no”. Options:

Yes

Parameter “Value of input 1 after bus recovery”

This parameter defines the default value of the object “Logic 1”after bus voltage recovery. Options::

Value before power off

Parameter “Value of input 2 after bus recovery”

This parameter defines the default value of the communication object “Logic 2” after bus voltage recovery, “1” or “0” is optional. Options:

Parameter setting description in the ETS
