- 34 / 37 -
Command
Code
Function Description
Example
Feedback Default Setting
s in x agc on
rate z!
Set the agc rate,
x=1~8,
z=10~200
s in 1 agc on
rate 30!
input
1 agc is
active
and set rate 3.0
s in x agc on
maxgain z!
Set the maximum gain value,
x=1~8,
z=0~120
s in 1 agc on
maxgain 60!
input 1 agc is
active and set
maxgain 6.0dB
s in x agc on
threshold z!
Set the threshold,
x=1~8,
z=-60~0
s in 1 agc on
threshold -50!
input 1 agc is active
and set threshold
-50dB
s in x agc off!
Disable Auto Gain Control,
x=1~8
s in 1 agc off!
input 1 agc is
unactive
Disable
Output
s out y mute! Mute on, y=0~8(0=all) s out 1 mute!
output 1 volume
mute
s out y mute off!
Mute off, y=0~8(0=all)
s out 1 mute off!
output 1 volume
mute off
s out y vol+ z!
Increase the volume by step,
y=0~8(0=all),
z=1~25
s out 1 vol+ 3!
output 1 volume
up
3dB to 3dB
s out y vol- z!
Decrease the volume by step,
y=0~8(0=all),
z=1~25
s out 1 vol- 3!
output 1 volume
down 3dB to -3dB
s out y lvl z!
Set the volume,
y=0~8(0=all),
z=-100~12
s out 1 lvl 3!
output 1 level is
3dB
r out y meter!
Get the meter information,
y=0~8(0=all)
r out 1 meter!
output
1 meter -64dB
r out y mute!
Get the mute status,
y=1~8
r out 1 mute!
output 1 volume
mute off
r out y lvl!
Get the level, y=0~8(0=all)
r out 1 lvl!
output 1 level is 0dB
Delay
s out y delay on
delay z!
Set the delay time,
y=1~8,
z=0~500
s out 1 delay on
delay 10!
output 1 delay is
active and delay
10ms
s out y delay off! Turn off delay, y=1~8
s out 1 delay off!
output 1 delay is
unactive
Off
r out y delay!
Get the delay status,
y=1~8
r out 1 delay!
output 1 delay is
unactive
Matrix Routing
s out y hit in x
lvl z!
Select settings, y=1~8,
x=1~12 (9-AM,10-AFC,
11-AEC,12-ANS),
z=-100~12
s out 1 hit in 1
lvl 3!
output 1 hit input 1
and set volume 3dB
s out y remove
in x!
Remove the input, y=1~8,
x=1~12 (9-AM,10-AFC,
11-AEC,12-ANS)
s out 1 remove
in 1!
output 1 remove
input 1
r out y matrix!
Get the routing status,
y=1~8
r out 1 matrix!
output 1 hit input
[1] volume [3]dB
Auto Mixer
s amx hit x!
Auto mixer, x=1~8
s amx hit 1!
automixer hit 1
s amx remove x!
Remove auto mixer, x=1~8
s amx remove 1!
automixer remove
1
