- 29 / 37 -
HDly (Delay)
<HDly></HDly>
The delay module is mainly used to delay sound playing.
Field
no: Channel number, no=100~107.
bypass: bypass or notbypass="1" (signal bypass)bypass="0" (not bypass).
><: Cut-off frequency. The value range is [0, 500]ms.
Example
<HDly no="104" bypass="0">300</HDly>
Indicates: Enable the delay module on output channel 104 (i.e. the analog output channel
5) with a delay value of 300ms.
HPeq (Parameter Equalizer)
<HPeq><Band>…</Band></HPeq>
The parameter equalizer is mainly used to adjust the specific frequency so that the overall frequency
response of the signal tends to be flat.
Field
no (in <HPeq></HPeq>): Channel number, no=0~7 or 100~107.
opt (in <HPeq></HPeq>): Equalizer enable/disable switch, opt="0" (Disable equalizer),
opt="1" (Enable equalizer).
no (in <Band></Band>): Subband number, no=0~7, the entire command must deliver 8
subbands simultaneously.
opt (in <HPeq></HPeq>): Subband enable/disable switch, opt="0" (Disable the filter
function of the corresponding subband), opt="1" (Enable the filter function of the
corresponding subband).
type: Filter type, type="1" (Low Pass Filter), type="2" (How Pass Filter),
type="5" (Peak value equalizer).
frq: Frequency, frq=20~20000Hz.
wd: Q value, wd=2~5000.
>< (in <Band></Band>): Subband gain value. The value range is [-240, 180].
Example
<HPeq no="3" opt="1">
<Band no="0" opt="0" type="5" frq="32" wd="70">0</Band>
<Band no="1" opt="0" type="5" frq="80" wd="70">0</Band>
<Band no="2" opt="0" type="5" frq="200" wd="70">0</Band>
<Band no="3" opt="1" type="5" frq="500" wd="70">-90</Band>
<Band no="4" opt="0" type="5" frq="1250" wd="70">0</Band>
<Band no="5" opt="0" type="5" frq="3150" wd="70">0</Band>
<Band no="6" opt="0" type="5" frq="8000" wd="70">0</Band>
<Band no="7" opt="0" type="5" frq="12000" wd="70">0</Band>
</HPeq>
Indicates: Enable the PEQ module on channel 3, and set the fourth subband as the peak
filter with a center frequency of 500Hz, Q value of 0.07, and gain value of -9dB.
HExp (Expander)
<HExp></HExp>
The expander is mainly used to compress the noise signals less than the threshold value so that the
noise can be removed.
Field
no: Channel number, no=0~7.
opt: Enable/disable switch, opt="0" (disable), opt="1" (enable).
thrd: Threshold value, thrd=-600~0.
rate: Compression rate, rate=10~200.
wd: Knee width, wd=0~200, wd="0"(Hard knee).
atktm: Attack time, atktm=1~500ms.
rlstm: Release time, rlstm=1~10000ms.
