- 28 / 37 -
HAhc (Adaptive Feedback Cancellation)
<HAhc><In>…</In></HAhc>
It is used to control the input source selection and other functions of the AFC module.
Field
ahc: Reserved
ans: ANS switch or noise suppression level for the AFC module, ans=0 or 6~18, ans="0"
(Disable ANS), ans="6"~"18" (noise suppression level).
no: Channel number, no=0~7 or 96.
Example
<HAhc ahc="1" ans="15">
<In no="1" ></In>
<In no="3"></In>
<In no="6" ></In>
<In no="96"></In>
</HAhc>
Indicates: Select input channels 1, 3, 6 and AM mixing signal to enter the Feedback
Cancellation module, and suppress 15dB noise at the same time.
HMmx (Matrix Mixer)
<HMmx><In>…</In></HMmx>
Matrix mixer can rout any input audio signal to any output.
Field
no (in <HMmx></HMmx>): Channel number, no=100~107.
no (in <In></In>): Channel number, no=0~7 or 96, 97, 98, 99.
>< (in <In></In>): Level value. The value range is [- 100, 12] dB.
Example
<HMmx no="100">
<In no="0">0</In>
<In no="1">0</In>
<In no="6">0</In>
</HMmx>
Indicates: Mixing input channel 0, 1, 6 to output channel 100 (i.e. the analog audio output
channel 1) .
HHpf (High Pass Filter)
<HHpf ></HHpf>
The high pass filter is mainly used to remove low frequency noise.
Field
no:
Channel number, no=100~107.
opt: Enable/disable switch, opt="0" (disable), opt="1" (enable).
><: Cut-off frequency. The value range is [20, 20000]Hz.
Example
<HHpf no="104" opt="1">300</HHpf>
Indicates: Enable the high pass filter on output channel 104 (i.e. the analog output channel
5) with a cut-off frequency of 300Hz.
HLpf (Low Pass Filter)
<HLpf></HLpf> It is used to control the
The low pass filter is mainly used to remove high frequency noise.
Field
no: Channel number, no=100~107.
opt: Enable/disable switch, opt="0" (disable), opt="1" (enable).
><:
Cut-off frequency. The value range is [20, 20000]Hz.
Example
<HLpf no="104" opt="1">1200</HLpf>
Indicates: Enable the low pass filter on output channel 104 (i.e. the analog output channel
5) with a cut-off frequency of 12000Hz.
