- 12 / 37 -
MAX GAIN: It will affect the smooth adjustment of the gain value of the signal between the
threshold and the target level, with a scale of [0.0, 12.0] dB.
THRESHOLD: Signals below threshold will remain unchanged while those between
threshold and target level will be amplified (at a ratio determined by the TARGET LEVEL,
RATIO and MAX GAIN). In order to ensure the work of the AGC process, the Target Level
must be set higher than Threshold. The threshold is recommended to set with a range of
[-60.0, 0.0]dB.
IN: Meter indicates the detected signal level before the AGC process.
OUT: Meter indicates the output signal level after the AGC process.
ACTIVE: Activates the AGC process. The function is equivalent to clicking the green letter A
at the AGC module on the HOME page.
A pair of up-down arrows on the right panel is available for you to select an input channel for
the AGC configuration.
5.8 Auto Mixer
The AUTO MIXER is built to set the order of priority for MIC/linear input when 8 MIC/LINE
ports are connected at one time.
As shown below, by clicking the AUTO MIXER section on the HOME page or the
AUTOMIXER tab on the menu bar, you will enter the AUTO MIXER setting page.
