overload is still active, the EVCS will stop charging and will not continue until the overload status is no longer
present + some timeout.
If the EVCS detects multiple overload situations within a certain period of time, the charging current will be
reduced by 10%.
The same applies to off-grid and grid-tied systems. For grid-tied systems, there is also an “input current limit”, and
the EVCS will work in the same way as described above if this limit is exceeded.
A warning is displayed on the web interface or in Victron Connect when charging power is reduced or charging is
interrupted.
K. Input current limit(A): In the case of a grid-tied system, it displays the input current limit setting from the inverter,
which serves as a threshold for 'Overload protection'.
c. EVCS ModbusTCP Server:
EVCS ModbusTCP server. The address is the same as that of the GX device.
i. IP address whitelist state: Enable or disable the whitelist state.
Note that when the IP address whitelist state is enabled, only the devices from the IP address whitelist table below
can communicate with the EVCS.
ii. IP address whitelist table: Add IP addresses that are allowed to communicate with the EVCS.
d. Date & Time:
i. Region: Select your time zone region.
ii. Time zone/Offset: Select the time zone. If UTC is selected, it is necessary to enter the correct offset.
Valid time format: +hh:mm or -hh:mm - Example: +02:00 or -01:00
Daylight saving time is processed automatically.
e. Others:
i. Energy price per kWh: Enter the cost per kWh to calculate the session cost saved.
ii. Device name: Change the name of the EV Charging Station NS, which will then also be updated in the GX device,
VictronConnect and the VRM portal.
3. Scheduler tab: The schedule required for the scheduled mode is created in this menu.
You can schedule scenes to activate automatically under certain conditions. These conditions include:
a. Start time: Start time of the schedule in hh:mm (24h time format applies)
b. End time: End time of the schedule in hh:mm (24h time format applies)
c. Current[6-32A]: Maximum charging current while the schedule is active
d. Repeat: The time interval at which the schedule is automatically executed again. Possible options:
i. Daily: Repeats daily
ii. Mon-Fri: Repeated from Monday to Friday
iii. Weekends: Repeats every weekend
iv. Custom: Choose the days of the week you want the scene to repeat
e. State: State of the scene. If disabled, the schedule for the scene will not run.
Once a scene has been created, press the Accept button and then the Save button. Note that the scenes are only active
when the charging station is in scheduled mode. A currently active scene is highlighted in green in the scheduler and marked
active. Scenes can be edited at any time. The same rules apply as described above.
Use the import and export buttons to import/export scenes in .json format.
4. Light Ring tab: Customises the ring of lights on the front of the station, around the vehicle socket. A variety of modes to
choose from, how long the mode is displayed, the brightness of the lights and their colour.
The coloured ring is to indicate at a glance what the EV Charging Station NS is doing: for example, when the vehicle is fully
charged, when there is a low state of charge.
Click the Save button at the bottom of the screen after any change or import/export the Light Ring settings in .json format.
5. Access tab: Change the username and password.
6. Backup & FW tab: Export or import saved settings, reset the charging station back to factory defaults and update firmware
manually.
Manual - EV Charging Station NS
Page 15 Setup
