5.2. EV Charging Station setup
After initial setup, set up the EVCS according to your needs. To do this, connect to the web interface and click on the Settings tab
for further setting options. The main page options are explained in The main page [17] chapter.
Six subtabs will appear:
1. Networks tab: See the Networks menu [18] chapter.
2. General tab: Provides setting options for the charger, GX device communication, display, time zone and device name.
a. Charger: Charger related settings.
i. EV charger position: Select where the EVCS is positioned in the system. Examples:
1. If the charging station is on the output of an inverter as one of the main’s AC outsources, select Inverter AC out.
2. If connected to the grid and the EVCS is positioned at the AC input of the grid before the inverter, select Inverter
AC in.
ii. EV charger autostart: If this option is enabled, the EVCS will attempt to start charging after the vehicle is connected.
iii. Contactor active when charged: Keeps the contactor closed after charging. If. for example, an air conditioner is
active in the vehicle, it is powered by AC power and not by the car battery.
iv. Maximum charging current: 10 - 32A
v. Minimum charging current: From 6A up to 1A below max. value. Example: A Renault Zoe needs at least 10A.
vi. CP line calibration procedure: If the vehicle is not detected or if the vehicle is fully charged and the EVCS contactor
opens/closes, the calibration should be performed.
vii. Power calibration(0.6 - 1.4): If the displayed power value is not correct, a maximum correction factor of +/- 40% can
be applied.
viii. Actual power (kW): Displays the current power value with which the EV is charged.
b. GX device: The EV Charging Station NS can be used:
i. As a stand alone device in Manual or Scheduled mode. Note that Auto mode requires a GX device and
communication between the GX device and EVCS must be enabled.
ii. As part of a larger Victron Energy system. When enabling GX device communication, Modbus TCP must be enabled
in the GX device (see Modbus TCP activation [20] section) itself to enable communication with the EVCS.
To avoid errors, the easiest way is to have the pairing between the EVCS and the GX device performed automatically.
With the Discover function, the EVCS is able to automatically detect the IP address via the VRM Portal ID.
A. Communication: Enable or disable communication with a GX device.
B. IP address: The IP address of your GX device. This will be automatically filled in when you use the Discover
feature to pair the EVCS with the GX device.
C. VRM Portal ID: The VRM Portal ID of your GX device. This will be automatically filled in when you use the
Discover feature to pair the EVCS with the GX device.
D. Discover: Click the Discover button to search for the GX device and pair the EVCS with the GX device.
Select the GX device from the list that will pop up; the GX IP address and VRM Portal ID will then be entered
automatically.
E. Check: Press this button to check communication with the GX device. The result is displayed at the top of the
page.
F. Start charging at backup battery SoC(%): The minimum backup battery SoC required to start charging in Auto
mode.
G. Stop charging at backup battery SoC, if off-grid(%): Stops charging when the backup battery SoC falls below
this value and there is no grid.
H. Allow battery/grid power for auto mode: When enabled, auto mode will continue to charge at minimum current
when there is insufficient excess solar power. Power is supplied from the grid or battery. This feature is useful to
reduce the number of auto-charge enable/disable cycles while charging in auto mode.
Note that EVCS cannot decide where to get power from (grid or battery), it's up to the inverter.
I. Battery/grid power timeout(min): The maximum timeout to stop drawing current from the battery/grid. This
parameter relates to 'Allow battery/grid power for auto mode'.
J. Overload protection: The EVCS reads the overload statuses from the inverter. When the inverter reports an
overload, the EVCS reduces the charging current to the minimum value and waits about 5 seconds. If the
Manual - EV Charging Station NS
Page 14 Setup
