- 7 -
PRESS BRAKE SET-UP
Do not bend material larger than 12” 20-gauge mild steel.
Failure to comply may cause serious injury and/or damage to the
machine.
To set up for bending:
1. Place a strip of wood (F, Figure 5) on bottom die, the full length of die.
2. Close brake until the wood contact supper dies(E).
3. Loosen screws (D) using 5mm hex key.
Figure 5
4. Select upper dies (E) for desired job and remove the others by sliding
them out the left end.（Included die set sizes1”x1, 2”x2, 3”x1, 4”x1）
5. Move operating handle until the wood pushes up the dies so that they
seat uniformly in upper beam.
6. Securely re-tighten all screws (Figure3), then release and remove wood
strip.
7. If making repeated bends or using along work piece, position guide rods
and plate for brake operation, as shown in Figure 3.
8. Scribe a line on workpiece for bend location. (Be sure to accommodate
bend allowance based upon thickness of material. This can be done either
