Rev. 7/8/2016 PS-4045, MANUAL.doc
Copyright 2016 Vestil Manufacturing Co. Page 5 of 8
(Optional) Caster Kit Installation Instructions:
Refer to FIG. 3 above for parts identifications. Numbers in parentheses correspond to item numbers in the table
above.
FIG. 3: (Optional) PS-RF-CK caster kit exploded parts diagram and bill of materials
Item
no.
Part no. Description Quantity
Item
no.
Part no. Description Quantity
1 15-516-025 Weldment, bracket, caster 2 7 37024
3
/
8
” – 16 grade 2 zinc finish lock nut 4
2 15-016-158 Bracket, caster clamp 4 8 21819
3
/
8
” – 16 x 1
1
/
2
” zinc-plated carriage
bolt
4
3 99-612-001 Bolt and nut combo.
3
/
8
” – 16 x 5” carriage bolt
3
/
8
” – 16 nut
4 9 11209
1
/
2
” – 16 x 1
1
/
2
” HHCS #2 zinc-plated
hex head bolt
4
4 16-132-261 6” x 2” glass filled nylon swivel
caster with brake
2 10 37030
1
/
2
” – 13 lock nut 4
5 16-132-263 6” x 2” glass filled nylon rigid caster 2 11 33012
1
/
2
” zinc finish, low carbon flat washer 4
6 33008
3
/
8
” USS zinc-finish flat washer 4
1. To install the optional caster kit, first lower the
tabletop completely to put the pallet stand into the
collapsed/storage configuration. Then, overturn the stand
so that the bottom of the frame is facing upwards.
2. When you receive the caster kit, the caster
clamping brackets (2) will still be attached to the
caster bracket weldment (1). Use a pair of pliers to
bend the mounting brackets back and forth until
they snap off of the weldments.
Caster clamping brackets
Caster bracket weldment (top view)
Mounting tab
Underside of
pallet stand
Mounting
tab
Clamping tab
Clamping
brackets
Caster bracket
Legs of rigid
casters are
vertical
Legs of swiveling
casters are angled
Caster brake
NOTE: Once a caster kit is installed on a
PS-4045 series pallet stand, the capacity
of the stand becomes 1,500 lb.
