Table of Contents Rev. 9/25/2023 LM-1T-8-24-TP/HBE MANUAL
Table of Contents Copyright 2022 Vestil Manufacturing Co. Page 5 of 14
Load Ratings for Varying Load Attachment Points and Boom
Extension Lengths
The center of gravity of the boom changes as boom length changes. As shown in the
diagram below, the horizontal center of gravity may be located at any point from RHCG to
EHCG:
Retracted horizontal center of gravity (RHCG): boom fully retracted and unloaded. RHCG
is measured from the “origin point” of the above diagram (edges of the fork pockets);
Extended horizontal center of gravity (EHCG): boom fully extended and unloaded. EHCG
is also measured from the “origin point” of the above diagram (edges of the fork pockets);
All other combinations of boom extension and load position produce a horizontal center
of gravity located somewhere between RHCG and EHCG.
Model
Extended horizontal
center of gravity
Retracted horizontal
center of gravity
Vertical center
of gravity
Horizontal
center
of gravity
Net weight
LM-1T-8-24-HBE-TP
52” (132.1 cm)
34
15
/
16
” (88.7 cm)
14”
35.6 cm
16”
40.6 cm
714 lb.
324.5 kg
LM-1T-8-24-HBE-DC
47
3
/
16
” (119.9 cm)
32
1
/
16
in. (81.4 cm)
13
1
/
8
”
33.3 cm
15
3
/
4
”
40.0 cm
805 lb.
365.9 kg
J I H G F E D C B A
= Center of gravity
Centers of gravity, net weight, and dimensions
Hook position
A
B
C
D
E
F
G
H
I
J
Distance from end of
boom in inches (cm)
36”
91 cm
48”
122 cm
60”
152 cm
72”
183 cm
84”
213 cm
96”
244 cm
108”
274 cm
120”
305 cm
132”
335 cm
144”
366 cm
Maximum rated load of a load suspended from a single hook located at the corresponding “Hook position”.
LM-1T-8-24-HBE-TP
8000 lb.
3636 kg
6650 lb.
3022 kg
6000 lb.
2727 kg
5300 lb.
2409 kg
4650 lb.
2113 kg
4000 lb.
1820 kg
3500 lb.
1590 kg
3000 lb.
1363 kg
2600 lb.
1181 kg
2200 lb.
1000 kg
LM-1T-8-24-HBE-DC
8000 lb.
3636 kg
6650 lb.
3022 kg
6000 lb.
2727 kg
5300 lb.
2409 kg
4650 lb.
2113 kg
4000 lb.
1820 kg
3500 lb.
1590 kg
3000 lb.
1363 kg
2600 lb.
1181 kg
2200 lb.
1000 kg
