LM-1T-8-24-HBE-DC Exploded View & Bill of Materials (08-006-398)
Item
Part No.
Description
Qty.
Item
Part no.
Description
Qty.
1
08-514-350
Weldment, frame, boom
1
19
11215
1
/
2
”-13 x 3”, hex bolt, gr. A, z-finish
4
2
08-514-354
Weldment, inner tube
1
20
33012
1
/
2
” flat washer, low carbon, z-finish
8
3
08-014-134
Frame, front support leg casting
1
21
01-112-015
Pin, cylinder pivot
1
4
08-145-002
Swivel hook, 3-ton
1
22
01-020-003
Boss, stop pin mount
1
5
08-145-005
Swivel hook, 5-ton
1
23
64133
3
/
16
” x 1” spring pin, plain finish
1
6
08-145-006
7
/
8
” – 6
1
/
2
ton shackle
1
24
05-527-300
Roller assembly
2
7
08-145-041
Snap hook,
5
/
16
”
1
25
28-112-043
3
/
4
” x 2” clevis pin, z-plated
1
8
99-145-019
Shackle,
5
/
8
”, 3-ton
1
26
33-112-034
3
/
4
” x 3
3
/
4
” clevis pin, z-plated
1
9
99-145-037
5
/
16
” chain 36” long
1
27
33426
3
/
4
” machined bushing, low carbon,
plain finish
2
10
99-145-084
Lap link
1
28
65078
Extended prong cotter pin,
1
/
8
”x1
1
/
2
”
2
11
11211
1
/
2
” -13UNC x 2” HHCS z-plated bolt
1
29
34314
1
1
/
8
”ID x 1
7
/
8
”OD split shaft collar
2
12
36110
1
/
2
” – 13UNC zinc-plated hex nut
1
30
33454
1
3
/
4
”-18ga. narrow machinery
bushing, plain finish
4
13
99-021-063
Cylinder, hydraulic, 1
1
/
4
” x 60”
1
31
11105
3
/
8
”-16 x 1” hex bolt, gr. A, z-plated
4
14
08-511-001
Weldment, bracket, cylinder end
mount
1
32
33622
3
/
8
” split lock washer, carbon steel,
medium z-finish
4
15
08-511-002
Weldment, bracket, cylinder mount
1
33
08-660-001
Power unit subassembly, 12VDC
(exploded view on p. 6)
1
16
11209
1
/
2
”-13 x 1
1
/
2
”, HHCS – ASTM A307, gr. A,
zinc-plated bolt
4
34
08-024-020
Guard, left power unit cover
1
17
37030
1
/
2
”-13 Nylon insert lock nut
8
35
08-024-021
Guard, right power unit cover
1
18
29-001-
017-001
Bumper, 6” x 3
3
/
16
” x 3”
2
36
32415
5
/
16
”-18 x
1
/
2
” thread cutting screw
2
