TABLE OF CONTENTS 6/15/2021 FHS MANUAL
TABLE OF CONTENTS Vestil Manufacturing Corp. Page 11 of 16
Step 5: Connect casters to legs.
a. Raise the crane off of the ground with a fork lift or hoist.
b. Attach a caster to the foot of each leg using the hardware shown.
c. Position a caster underneath each foot as shown in the diagrams
below.
Fig. 5C: Caster attachment (FHS-
6 models)
1 8” x 3” phenolic 4-
way swivel lock
caster
2
7
/
16
in. zinc-plated lock washer
3
7
/
16
in. –
14UNC x 1 in. HHCS #5
zinc-plated bolt
3
Fig. 5E: Caster attachment
(FHS-10 models)
1 ½ in. – 13 x 1½ in. HHCS #2 zinc-
plated bolt
2 8in. x 3in. ductile steel caster
3 Batwing caster position
lock
4 ½ in. – 13 lock nut
Fig. 5A: Caster attachment
(FHS-2 and FHS-4 models)
1 GFN-8/2-S caster
2
5
/
16
in. zinc-plated USS flat washer
3
5
/
16
in. zinc-plated lock washer
4
5
/
16
in. – 18 x
3
/
4
in. HHCS #2 zinc-
plated bolt
Fig. 5: Caster attachment
Fig. 5D: Caster attachment (FHS-
8 models)
1
1
/
2
in. – 13 lock nut
2 8” x 3” phenolic 4-
way swivel
lock caster
3
1
/
2
in. – 13 x 1
1
/
2
in HHCS #2 zinc-
plated bolt
1
2
3
4
1
2
3
1
2
3
1
2
3
4
Fig. 5B: Dual pneumatic caster
2 Dual pneumatic caster
3 Caster mount bracket
5
1
/
2
” -13 zinc-plated hex nut
6
1
/
2
” zinc finish flat washer
4
1
/
2
” -13 x 1
1
/
4
” HHCS #2 zinc-
plated bolt
7
1
/
2
” plain finish lock washer
(medium split)
15
5
/
16
” plain finish lock washer
(medium split)
16
5
/
16
” -18 x
3
/
4
” HHCS #2, zinc-
plated
17
5
/
16
” zinc plated flat washer
